提供对象的替代品或其占位符。 代理控制着对于原对象的访问, 并允许在将请求提交给对象前后进行一些处理。
// 远程服务接口。
interface ThirdPartyTVLib is
method listVideos()
method getVideoInfo(id)
method downloadVideo(id)
// 服务连接器的具体实现。该类的方法可以向腾讯视频请求信息。请求速度取决于
// 用户和腾讯视频的互联网连接情况。如果同时发送大量请求,即使所请求的信息
// 一模一样,程序的速度依然会减慢。
class ThirdPartyTVClass implements ThirdPartyTVLib is
method listVideos() is
// 向腾讯视频发送一个 API 请求。
method getVideoInfo(id) is
// 获取某个视频的元数据。
method downloadVideo(id) is
// 从腾讯视频下载一个视频文件。
// 为了节省网络带宽,我们可以将请求结果缓存下来并保存一段时间。但你可能无
// 法直接将这些代码放入服务类中。比如该类可能是第三方程序库的一部分或其签
// 名是`final(最终)`。因此我们会在一个实现了服务类接口的新代理类中放入
// 缓存代码。当代理类接收到真实请求后,才会将其委派给服务对象。
class CachedTVClass implements ThirdPartyTVLib is
private field service: ThirdPartyTVLib
private field listCache, videoCache
field needReset
constructor CachedTVClass(service: ThirdPartyTVLib) is
this.service = service
method listVideos() is
if (listCache == null || needReset)
listCache = service.listVideos()
return listCache
method getVideoInfo(id) is
if (videoCache == null || needReset)
videoCache = service.getVideoInfo(id)
return videoCache
method downloadVideo(id) is
if (!downloadExists(id) || needReset)
service.downloadVideo(id)
// 之前直接与服务对象交互的 GUI 类不需要改变,前提是它仅通过接口与服务对
// 象交互。我们可以安全地传递一个代理对象来代替真实服务对象,因为它们都实
// 现了相同的接口。
class TVManager is
protected field service: ThirdPartyTVLib
constructor TVManager(service: ThirdPartyTVLib) is
this.service = service
method renderVideoPage(id) is
info = service.getVideoInfo(id)
// 渲染视频页面。
method renderListPanel() is
list = service.listVideos()
// 渲染视频缩略图列表。
method reactOnUserInput() is
renderVideoPage()
renderListPanel()
// 程序可在运行时对代理进行配置。
class Application is
method init() is
aTVService = new ThirdPartyTVClass()
aTVProxy = new CachedTVClass(aTVService)
manager = new TVManager(aTVProxy)
manager.reactOnUserInput()
/**
* The Subject interface declares common operations for both RealSubject and the
* Proxy. As long as the client works with RealSubject using this interface,
* you'll be able to pass it a proxy instead of a real subject.
*/
interface Subject {
request(): void;
}
/**
* The RealSubject contains some core business logic. Usually, RealSubjects are
* capable of doing some useful work which may also be very slow or sensitive -
* e.g. correcting input data. A Proxy can solve these issues without any
* changes to the RealSubject's code.
*/
class RealSubject implements Subject {
public request(): void {
console.log('RealSubject: Handling request.');
}
}
/**
* The Proxy has an interface identical to the RealSubject.
*/
class Proxy implements Subject {
private realSubject: RealSubject;
/**
* The Proxy maintains a reference to an object of the RealSubject class. It
* can be either lazy-loaded or passed to the Proxy by the client.
*/
constructor(realSubject: RealSubject) {
this.realSubject = realSubject;
}
/**
* The most common applications of the Proxy pattern are lazy loading,
* caching, controlling the access, logging, etc. A Proxy can perform one of
* these things and then, depending on the result, pass the execution to the
* same method in a linked RealSubject object.
*/
public request(): void {
if (this.checkAccess()) {
this.realSubject.request();
this.logAccess();
}
}
private checkAccess(): boolean {
// Some real checks should go here.
console.log('Proxy: Checking access prior to firing a real request.');
return true;
}
private logAccess(): void {
console.log('Proxy: Logging the time of request.');
}
}
/**
* The client code is supposed to work with all objects (both subjects and
* proxies) via the Subject interface in order to support both real subjects and
* proxies. In real life, however, clients mostly work with their real subjects
* directly. In this case, to implement the pattern more easily, you can extend
* your proxy from the real subject's class.
*/
function clientCode(subject: Subject) {
// ...
subject.request();
// ...
}
console.log('Client: Executing the client code with a real subject:');
const realSubject = new RealSubject();
clientCode(realSubject);
console.log('');
console.log('Client: Executing the same client code with a proxy:');
const proxy = new Proxy(realSubject);
clientCode(proxy);
