绘图技巧 - 绘制赛博朋克风的优秀第三方R包-ggCyberPunk - 《AI》

R-ggCyberPunk包简介
R-ggCyberPunk包实例演示
参考资料

数据可视化 R

R-ggCyberPunk包简介

R-ggCyberPunk包作为基于ggplot2、专门绘制赛博朋克风的第三方包，其提供的绘制函数有限，主要包括以下几个：

geom_glowing_area()：绘制赛博朋克风发光区域图(area plot)。
geom_glowing_line()：绘制赛博朋克风发光线图(line plot )。
geom_linesaber():绘制赛博朋克风激光剑外观线图(line plot)。
theme_cyberpunk():绘制赛博朋克风绘图主题。

更多参数信息可参考：R-ggCyberPunk介绍

R-ggCyberPunk包实例演示

这一部分就列举使用几个 R-ggCyberPunk包绘制赛博朋克风的可视化作品，如下：

「`geom_glowing_area()`」：

library(tidyverse)
library(ggtext)
library(hrbrthemes)
library(ggCyberPunk)
df = data.frame(A=c(1,4,4,6,7,5,1),
               B=c(4,3,5,7,5,6,7),
               Time=c(1,2,3,4,5,6,7)) %>%
# 将数据准换成DF类型
pivot_longer(cols = c(A,B),names_to = "group", values_to = "count")
#可视化绘制
plot01 <- ggplot(data = df,aes(x=Time, y = count, color = group, fill= group))+
     geom_glowing_area()+
     scale_fill_cyberpunk("zune")+
     scale_color_cyberpunk("zune")+
    labs(
    title = "Example of <span style='color:#D20F26'>ggCyberPunk::geom_glowing_area function</span>",
    subtitle = "processed charts with <span style='color:#1A73E8'>geom_glowing_area()</span>",
    caption = "Visualization by <span style='color:#0057FF'>DataCharm</span>") +
  theme_cyberpunk(font = "Roboto Condensed")+
  theme(
    plot.title = element_markdown(hjust = 0.5,vjust = .5,color = "black",
                                  size = 20, margin = margin(t = 1, b = 12)),
    plot.subtitle = element_markdown(hjust = 0,vjust = .5,size=15),
    plot.caption = element_markdown(hjust = 1,face = 'bold',size = 12)
      )

Example Of geom_glowing_area()with zune
注意：这里scale_fill_cyberpunk() 中可设置main, zune,cotton candy, laser sword 四种选项。效果分别如下：
「main」:

Example Of geom_glowing_area()with main
「cotton candy」:

Example Of geom_glowing_area()with cotton candy
「laser sword」:

Example Of geom_glowing_area()with laser sword

「`geom_glowing_line()`」：

df = data.frame(A=c(1,4,4,6,7,5,1),
               B=c(4,3,5,7,5,6,7),
               Time=c(1,2,3,4,5,6,7)) %>%
pivot_longer(cols = c(A,B),names_to = "group", values_to = "count")
plot2 <- ggplot(data = df,aes(x=Time, y = count, color = group, fill= group))+
     geom_glowing_line()+
     scale_color_cyberpunk()+
     labs(
    title = "Example of <span style='color:#D20F26'>ggCyberPunk::geom_glowing_line function</span>",
    subtitle = "processed charts with <span style='color:#1A73E8'>geom_glowing_line()</span>",
    caption = "Visualization by <span style='color:#0057FF'>DataCharm</span>") +
  theme_cyberpunk(font = "Roboto Condensed")+
  theme(
    plot.title = element_markdown(hjust = 0.5,vjust = .5,color = "black",
                                  size = 20, margin = margin(t = 1, b = 12)),
    plot.subtitle = element_markdown(hjust = 0,vjust = .5,size=15),
    plot.caption = element_markdown(hjust = 1,face = 'bold',size = 12)
      )

Example Of geom_glowing_line()

「`geom_linesaber()`」：

df = data.frame(A=c(1,4,4,6,7,5,1),
               B=c(4,3,5,7,5,6,7),
               Time=c(1,2,3,4,5,6,7)) %>%
pivot_longer(cols = c(A,B),names_to = "group", values_to = "count")
plot3 <- ggplot(data = df,aes(x=Time, y = count, color = group, fill= group))+
     geom_linesaber()+
     theme_cyberpunk()+
     scale_color_cyberpunk(reverse = T)+
    labs(
    title = "Example of <span style='color:#D20F26'>ggCyberPunk::geom_linesaber function</span>",
    subtitle = "processed charts with <span style='color:#1A73E8'>geom_linesaber()</span>",
    caption = "Visualization by <span style='color:#0057FF'>DataCharm</span>") +
  theme_cyberpunk(font = "Roboto Condensed")+
  theme(
    plot.title = element_markdown(hjust = 0.5,vjust = .5,color = "black",
                                  size = 20, margin = margin(t = 1, b = 12)),
    plot.subtitle = element_markdown(hjust = 0,vjust = .5,size=15),
    plot.caption = element_markdown(hjust = 1,face = 'bold',size = 12)
      )

Example Of geom_linesaber()
以上就是简单介绍了R-ggCyberPunk包三个绘图函数，接下里，使用改包主题对常见图表进行朋克风格图表绘制，如下：

「geom_boxplot」：箱线图

plot4 <- ggplot(mpg, aes(class, hwy,fill=factor(drv))) +
  geom_boxplot() +
  scale_fill_cyberpunk("zune",name="")+
    labs(
    title = "Example of <span style='color:#D20F26'>ggCyberPunk::scale_fill_cyberpunk function</span>",
    subtitle = "processed charts with <span style='color:#1A73E8'>scale_fill_cyberpunk()</span>",
    caption = "Visualization by <span style='color:#0057FF'>DataCharm</span>") +
  theme_cyberpunk(font = "Roboto Condensed")+
  theme(
    plot.title = element_markdown(hjust = 0.5,vjust = .5,color = "black",
                                  size = 20, margin = margin(t = 1, b = 12)),
    plot.subtitle = element_markdown(hjust = 0,vjust = .5,size=15),
    plot.caption = element_markdown(hjust = 1,face = 'bold',size = 12)
      )

Example Of ggplot2::geom_boxplot() with theme_cyberpunk()
当然，还可以设置其他颜色风格的样式。如果不喜欢R绘制类似的图表，可以试试python的可视化库－mplcyberpunk，更多关于mplcyberpunk库的详细内容大家可参考：Python－mplcyberpunk库

参考资料

R-ggCyberPunk介绍：https://github.com/delabj/ggCyberPunk
python－mplcyberpunk库：https://github.com/dhaitz/mplcyberpunk
