一、前言

1、版本

apache-shardingsphere-5.0.0-shardingsphere-proxy-bin

下载页面 https://www.apache.org/dyn/closer.cgi/shardingsphere/5.0.0/apache-shardingsphere-5.0.0-shardingsphere-proxy-bin.tar.gz

二、快速开始

1、配置文件

分表需要配置两个文件（server.yaml、config-sharding.yaml）

server.yaml

rules:
  - !AUTHORITY
    users:
      - root@%:root
      - sharding@:sharding
    provider:
      type: ALL_PRIVILEGES_PERMITTED
  - !TRANSACTION
    defaultType: XA
    providerType: Atomikos
props:
  max-connections-size-per-query: 1
  kernel-executor-size: 16  # Infinite by default.
  proxy-frontend-flush-threshold: 128  # The default value is 128.
  proxy-opentracing-enabled: false
  proxy-hint-enabled: false
  sql-show: false
  check-table-metadata-enabled: false
  show-process-list-enabled: false
    # Proxy backend query fetch size. A larger value may increase the memory usage of ShardingSphere Proxy.
  # The default value is -1, which means set the minimum value for different JDBC drivers.
  proxy-backend-query-fetch-size: -1
  check-duplicate-table-enabled: false
  sql-comment-parse-enabled: false
  proxy-frontend-executor-size: 0 # Proxy frontend executor size. The default value is 0, which means let Netty decide.
    # Available options of proxy backend executor suitable: OLAP(default), OLTP. The OLTP option may reduce time cost of writing packets to client, but it may increase the latency of SQL execution
  # if client connections are more than proxy-frontend-netty-executor-size, especially executing slow SQL.
  proxy-backend-executor-suitable: OLAP
  proxy-frontend-max-connections: 0 # Less than or equal to 0 means no limitation.
  sql-federation-enabled: false

config-sharding.yaml

schemaName: sharding_db
dataSources:
 ds_0:
   url: jdbc:mysql://localhost:3306/smiler_user?useUnicode=true&characterEncoding=utf8&serverTimezone=UTC
   username: root
   password: 123456
   connectionTimeoutMilliseconds: 30000
   idleTimeoutMilliseconds: 60000
   maxLifetimeMilliseconds: 1800000
   maxPoolSize: 50
   minPoolSize: 1
rules:
- !SHARDING
 tables:
   smiler_user:
     actualDataNodes: ds_0.smiler_user_$->{1..2}
     tableStrategy:
       standard:
         shardingColumn: id
         shardingAlgorithmName: smiler-user-inline
 shardingAlgorithms:
   smiler-user-inline:
     type: INLINE
     props:
       algorithm-expression: smiler_user_${id % 2 + 1}
