- Synchornized重量级锁 中park()调用的是 pthread_**mutex**_init() 方法
- ReentrantLock 中调用的LockSupport.park()所调用的 pthread_**cond**_init() 方法
- 两者都会进入内核态,区别不大。
objectMonitor.cpp
void ObjectMonitor::enter(TRAPS) {// The following code is ordered to check the most common cases first// and to reduce RTS->RTO cache line upgrades on SPARC and IA32 processors.Thread * const Self = THREAD;void * cur = Atomic::cmpxchg(Self, &_owner, (void*)NULL);//看当前持有锁的线程是否为null， 直接获取锁， 非公平if (cur == NULL) {// Either ASSERT _recursions == 0 or explicitly set _recursions = 0.assert(_recursions == 0, "invariant");assert(_owner == Self, "invariant");return;}//重入if (cur == Self) {// TODO-FIXME: check for integer overflow! BUGID 6557169._recursions++;return;}if (Self->is_lock_owned ((address)cur)) {assert(_recursions == 0, "internal state error");_recursions = 1;// Commute owner from a thread-specific on-stack BasicLockObject address to// a full-fledged "Thread *"._owner = Self;return;}// We've encountered genuine contention.assert(Self->_Stalled == 0, "invariant");Self->_Stalled = intptr_t(this);// Try one round of spinning *before* enqueueing Self// and before going through the awkward and expensive state// transitions. The following spin is strictly optional ...// Note that if we acquire the monitor from an initial spin// we forgo posting JVMTI events and firing DTRACE probes.// 自旋if (TrySpin(Self) > 0) {assert(_owner == Self, "invariant");assert(_recursions == 0, "invariant");assert(((oop)(object()))->mark() == markOopDesc::encode(this), "invariant");Self->_Stalled = 0;return;}assert(_owner != Self, "invariant");assert(_succ != Self, "invariant");assert(Self->is_Java_thread(), "invariant");JavaThread * jt = (JavaThread *) Self;assert(!SafepointSynchronize::is_at_safepoint(), "invariant");assert(jt->thread_state() != _thread_blocked, "invariant");assert(this->object() != NULL, "invariant");assert(_count >= 0, "invariant");// Prevent deflation at STW-time. See deflate_idle_monitors() and is_busy().// Ensure the object-monitor relationship remains stable while there's contention.Atomic::inc(&_count);JFR_ONLY(JfrConditionalFlushWithStacktrace<EventJavaMonitorEnter> flush(jt);)EventJavaMonitorEnter event;if (event.should_commit()) {event.set_monitorClass(((oop)this->object())->klass());event.set_address((uintptr_t)(this->object_addr()));}{ // Change java thread status to indicate blocked on monitor enter.JavaThreadBlockedOnMonitorEnterState jtbmes(jt, this);Self->set_current_pending_monitor(this);DTRACE_MONITOR_PROBE(contended__enter, this, object(), jt);if (JvmtiExport::should_post_monitor_contended_enter()) {JvmtiExport::post_monitor_contended_enter(jt, this);// The current thread does not yet own the monitor and does not// yet appear on any queues that would get it made the successor.// This means that the JVMTI_EVENT_MONITOR_CONTENDED_ENTER event// handler cannot accidentally consume an unpark() meant for the// ParkEvent associated with this ObjectMonitor.}OSThreadContendState osts(Self->osthread());ThreadBlockInVM tbivm(jt);// TODO-FIXME: change the following for(;;) loop to straight-line code.for (;;) {jt->set_suspend_equivalent();// cleared by handle_special_suspend_equivalent_condition()// or java_suspend_self()EnterI(THREAD);if (!ExitSuspendEquivalent(jt)) break;// We have acquired the contended monitor, but while we were// waiting another thread suspended us. We don't want to enter// the monitor while suspended because that would surprise the// thread that suspended us.//_recursions = 0;_succ = NULL;exit(false, Self);jt->java_suspend_self();}Self->set_current_pending_monitor(NULL);// We cleared the pending monitor info since we've just gotten past// the enter-check-for-suspend dance and we now own the monitor free// and clear, i.e., it is no longer pending. The ThreadBlockInVM// destructor can go to a safepoint at the end of this block. If we// do a thread dump during that safepoint, then this thread will show// as having "-locked" the monitor, but the OS and java.lang.Thread// states will still report that the thread is blocked trying to// acquire it.}Atomic::dec(&_count);assert(_count >= 0, "invariant");Self->_Stalled = 0;// Must either set _recursions = 0 or ASSERT _recursions == 0.assert(_recursions == 0, "invariant");assert(_owner == Self, "invariant");assert(_succ != Self, "invariant");assert(((oop)(object()))->mark() == markOopDesc::encode(this), "invariant");// The thread -- now the owner -- is back in vm mode.// Report the glorious news via TI,DTrace and jvmstat.// The probe effect is non-trivial. All the reportage occurs// while we hold the monitor, increasing the length of the critical// section. Amdahl's parallel speedup law comes vividly into play.//// Another option might be to aggregate the events (thread local or// per-monitor aggregation) and defer reporting until a more opportune// time -- such as next time some thread encounters contention but has// yet to acquire the lock. While spinning that thread could// spinning we could increment JVMStat counters, etc.DTRACE_MONITOR_PROBE(contended__entered, this, object(), jt);if (JvmtiExport::should_post_monitor_contended_entered()) {JvmtiExport::post_monitor_contended_entered(jt, this);// The current thread already owns the monitor and is not going to// call park() for the remainder of the monitor enter protocol. So// it doesn't matter if the JVMTI_EVENT_MONITOR_CONTENDED_ENTERED// event handler consumed an unpark() issued by the thread that// just exited the monitor.}if (event.should_commit()) {event.set_previousOwner((uintptr_t)_previous_owner_tid);event.commit();}OM_PERFDATA_OP(ContendedLockAttempts, inc());}
自旋中调用的 EnterI 方法
void ObjectMonitor::EnterI(TRAPS) {
Thread * const Self = THREAD;
assert(Self->is_Java_thread(), "invariant");
assert(((JavaThread *) Self)->thread_state() == _thread_blocked, "invariant");
// Try the lock - TATAS
if (TryLock (Self) > 0) {
assert(_succ != Self, "invariant");
assert(_owner == Self, "invariant");
assert(_Responsible != Self, "invariant");
return;
}
assert(InitDone, "Unexpectedly not initialized");
// We try one round of spinning *before* enqueueing Self.
//
// If the _owner is ready but OFFPROC we could use a YieldTo()
// operation to donate the remainder of this thread's quantum
// to the owner. This has subtle but beneficial affinity
// effects.
if (TrySpin(Self) > 0) {
assert(_owner == Self, "invariant");
assert(_succ != Self, "invariant");
assert(_Responsible != Self, "invariant");
return;
}
// The Spin failed -- Enqueue and park the thread ...
assert(_succ != Self, "invariant");
assert(_owner != Self, "invariant");
assert(_Responsible != Self, "invariant");
// Enqueue "Self" on ObjectMonitor's _cxq.
//
// Node acts as a proxy for Self.
// As an aside, if were to ever rewrite the synchronization code mostly
// in Java, WaitNodes, ObjectMonitors, and Events would become 1st-class
// Java objects. This would avoid awkward lifecycle and liveness issues,
// as well as eliminate a subset of ABA issues.
// TODO: eliminate ObjectWaiter and enqueue either Threads or Events.
ObjectWaiter node(Self);
Self->_ParkEvent->reset();
node._prev = (ObjectWaiter *) 0xBAD;
node.TState = ObjectWaiter::TS_CXQ;
// Push "Self" onto the front of the _cxq.
// Once on cxq/EntryList, Self stays on-queue until it acquires the lock.
// Note that spinning tends to reduce the rate at which threads
// enqueue and dequeue on EntryList|cxq.
ObjectWaiter * nxt;
for (;;) {
node._next = nxt = _cxq;
if (Atomic::cmpxchg(&node, &_cxq, nxt) == nxt) break;
// Interference - the CAS failed because _cxq changed. Just retry.
// As an optional optimization we retry the lock.
if (TryLock (Self) > 0) {
assert(_succ != Self, "invariant");
assert(_owner == Self, "invariant");
assert(_Responsible != Self, "invariant");
return;
}
}
// Check for cxq|EntryList edge transition to non-null. This indicates
// the onset of contention. While contention persists exiting threads
// will use a ST:MEMBAR:LD 1-1 exit protocol. When contention abates exit
// operations revert to the faster 1-0 mode. This enter operation may interleave
// (race) a concurrent 1-0 exit operation, resulting in stranding, so we
// arrange for one of the contending thread to use a timed park() operations
// to detect and recover from the race. (Stranding is form of progress failure
// where the monitor is unlocked but all the contending threads remain parked).
// That is, at least one of the contended threads will periodically poll _owner.
// One of the contending threads will become the designated "Responsible" thread.
// The Responsible thread uses a timed park instead of a normal indefinite park
// operation -- it periodically wakes and checks for and recovers from potential
// strandings admitted by 1-0 exit operations. We need at most one Responsible
// thread per-monitor at any given moment. Only threads on cxq|EntryList may
// be responsible for a monitor.
//
// Currently, one of the contended threads takes on the added role of "Responsible".
// A viable alternative would be to use a dedicated "stranding checker" thread
// that periodically iterated over all the threads (or active monitors) and unparked
// successors where there was risk of stranding. This would help eliminate the
// timer scalability issues we see on some platforms as we'd only have one thread
// -- the checker -- parked on a timer.
if (nxt == NULL && _EntryList == NULL) {
// Try to assume the role of responsible thread for the monitor.
// CONSIDER: ST vs CAS vs { if (Responsible==null) Responsible=Self }
Atomic::replace_if_null(Self, &_Responsible);
}
// The lock might have been released while this thread was occupied queueing
// itself onto _cxq. To close the race and avoid "stranding" and
// progress-liveness failure we must resample-retry _owner before parking.
// Note the Dekker/Lamport duality: ST cxq; MEMBAR; LD Owner.
// In this case the ST-MEMBAR is accomplished with CAS().
//
// TODO: Defer all thread state transitions until park-time.
// Since state transitions are heavy and inefficient we'd like
// to defer the state transitions until absolutely necessary,
// and in doing so avoid some transitions ...
int nWakeups = 0;
int recheckInterval = 1;
for (;;) {
if (TryLock(Self) > 0) break;
assert(_owner != Self, "invariant");
// park self
if (_Responsible == Self) {
Self->_ParkEvent->park((jlong) recheckInterval);
// Increase the recheckInterval, but clamp the value.
recheckInterval *= 8;
if (recheckInterval > MAX_RECHECK_INTERVAL) {
recheckInterval = MAX_RECHECK_INTERVAL;
}
} else {
//_ParkEvent 根据当前操作系统调用对应的park方法 在Linux中调用的就是pthread_mutex_init
Self->_ParkEvent->park();
}
if (TryLock(Self) > 0) break;
// The lock is still contested.
// Keep a tally of the # of futile wakeups.
// Note that the counter is not protected by a lock or updated by atomics.
// That is by design - we trade "lossy" counters which are exposed to
// races during updates for a lower probe effect.
// This PerfData object can be used in parallel with a safepoint.
// See the work around in PerfDataManager::destroy().
OM_PERFDATA_OP(FutileWakeups, inc());
++nWakeups;
// Assuming this is not a spurious wakeup we'll normally find _succ == Self.
// We can defer clearing _succ until after the spin completes
// TrySpin() must tolerate being called with _succ == Self.
// Try yet another round of adaptive spinning.
if (TrySpin(Self) > 0) break;
// We can find that we were unpark()ed and redesignated _succ while
// we were spinning. That's harmless. If we iterate and call park(),
// park() will consume the event and return immediately and we'll
// just spin again. This pattern can repeat, leaving _succ to simply
// spin on a CPU.
if (_succ == Self) _succ = NULL;
// Invariant: after clearing _succ a thread *must* retry _owner before parking.
OrderAccess::fence();
}
// Egress :
// Self has acquired the lock -- Unlink Self from the cxq or EntryList.
// Normally we'll find Self on the EntryList .
// From the perspective of the lock owner (this thread), the
// EntryList is stable and cxq is prepend-only.
// The head of cxq is volatile but the interior is stable.
// In addition, Self.TState is stable.
assert(_owner == Self, "invariant");
assert(object() != NULL, "invariant");
// I'd like to write:
// guarantee (((oop)(object()))->mark() == markOopDesc::encode(this), "invariant") ;
// but as we're at a safepoint that's not safe.
UnlinkAfterAcquire(Self, &node);
if (_succ == Self) _succ = NULL;
assert(_succ != Self, "invariant");
if (_Responsible == Self) {
_Responsible = NULL;
OrderAccess::fence(); // Dekker pivot-point
// We may leave threads on cxq|EntryList without a designated
// "Responsible" thread. This is benign. When this thread subsequently
// exits the monitor it can "see" such preexisting "old" threads --
// threads that arrived on the cxq|EntryList before the fence, above --
// by LDing cxq|EntryList. Newly arrived threads -- that is, threads
// that arrive on cxq after the ST:MEMBAR, above -- will set Responsible
// non-null and elect a new "Responsible" timer thread.
//
// This thread executes:
// ST Responsible=null; MEMBAR (in enter epilogue - here)
// LD cxq|EntryList (in subsequent exit)
//
// Entering threads in the slow/contended path execute:
// ST cxq=nonnull; MEMBAR; LD Responsible (in enter prolog)
// The (ST cxq; MEMBAR) is accomplished with CAS().
//
// The MEMBAR, above, prevents the LD of cxq|EntryList in the subsequent
// exit operation from floating above the ST Responsible=null.
}
// We've acquired ownership with CAS().
// CAS is serializing -- it has MEMBAR/FENCE-equivalent semantics.
// But since the CAS() this thread may have also stored into _succ,
// EntryList, cxq or Responsible. These meta-data updates must be
// visible __before this thread subsequently drops the lock.
// Consider what could occur if we didn't enforce this constraint --
// STs to monitor meta-data and user-data could reorder with (become
// visible after) the ST in exit that drops ownership of the lock.
// Some other thread could then acquire the lock, but observe inconsistent
// or old monitor meta-data and heap data. That violates the JMM.
// To that end, the 1-0 exit() operation must have at least STST|LDST
// "release" barrier semantics. Specifically, there must be at least a
// STST|LDST barrier in exit() before the ST of null into _owner that drops
// the lock. The barrier ensures that changes to monitor meta-data and data
// protected by the lock will be visible before we release the lock, and
// therefore before some other thread (CPU) has a chance to acquire the lock.
// See also: http://gee.cs.oswego.edu/dl/jmm/cookbook.html.
//
// Critically, any prior STs to _succ or EntryList must be visible before
// the ST of null into _owner in the *subsequent* (following) corresponding
// monitorexit. Recall too, that in 1-0 mode monitorexit does not necessarily
// execute a serializing instruction.
return;
}
