web综合案例
学习目标
目标1：完成使用POI读写Excel的测试案例
目标2：完成题目模板的制作，包括表头，标题及数据
目标3：完成题目报表数据导出的业务功能
目标4：完成角色与模块功能的快速开发
目标5：能够自己独立分析树形控件的页面制作
目标6：完成授权时动态加载授权数据
目标7：完成角色与模块的绑定关系
1. 报表
报表：简单的说，报表就是用表格、图表等格式来动态显示数据，可以用公式表示为：“报表 = 多样的格式 + 动态的数据”。
报表的种类有很多：Excel报表，PDF报表，网页报表等，他们各有优缺点
在本课程中，我们主要来将Excel报表。
对于Excel报表的技术实现上也有很多种选择：
- JXL：支持xls文件操作
- POI：支持xls和xlsx文件操作
我们只要来讲POI技术，要使用POI就要导入其坐标，如下
<!--POI-->
<dependency>
<groupId>org.apache.poi</groupId>
<artifactId>poi</artifactId>
<version>4.0.1</version>
</dependency>
<dependency>
<groupId>org.apache.poi</groupId>
<artifactId>poi-ooxml</artifactId>
<version>4.0.1</version>
</dependency>
<dependency>
<groupId>org.apache.poi</groupId>
<artifactId>poi-ooxml-schemas</artifactId>
<version>4.0.1</version>
</dependency>
1.1 POI写Excel文件
在测试包下创建POI测试类：com.itheima.service.store.PoiTest
public class PoiTest {
@Test
public void testWriteByPoi() throws IOException {
//1.获取到对应的Excel文件，工作簿文件
Workbook wb = new XSSFWorkbook();
//2.创建工作表
Sheet sheet = wb.createSheet();
wb.createSheet("这是啥呀");
//3.创建工作表中的行对象
Row row = sheet.createRow(1);
//4.创建工作表中行中的列对象
Cell cell = row.createCell(1);
//5.在列中写数据
cell.setCellValue("测试一下单元格");
//创建一个文件对象，作为excel文件内容的输出文件
File f = new File("test.xlsx");
//输出时通过流的形式对外输出，包装对应的目标文件
OutputStream os = new FileOutputStream(f);
//将内存中的workbook数据写入到流中
wb.write(os);
wb.close();
os.close();
}
}
1.2 POI读Excel文件
创建读Excel的测试方法：testReadByPoi
@Test
public void testReadByPoi() throws IOException {
//1.获取要读取的文件工作簿对象
Workbook wb = new XSSFWorkbook("test.xlsx");
//2.获取工作表
Sheet s = wb.getSheetAt(0);
//3.获取行
Row row = s.getRow(3);
//4.获取列
Cell cell = row.getCell(1);
//5.根据数据的类型获取数据
// String data = cell.getStringCellValue();
// double data = cell.getNumericCellValue();
boolean data = cell.getBooleanCellValue();
System.out.println(data);
wb.close();
}
1.3 题目模板表头制作
前两节我们讲了如何去读取及写入Excel数据，操作相对简单，但是实际业务中我们要操作的Excel报表还是比较繁琐的，我们可以从今日课程资料中找到我们最终要导出报表的模板：资料\Excel解析\模板.xlsx
这种形式的我们如何去操作呢？
在测试类中再编写一个测试方法：testProjectPoi
@Test
public void testProjectPoi() throws IOException {
//1.获取到对应的Excel文件，工作簿文件
Workbook wb = new XSSFWorkbook();
//2.创建工作表
Sheet s = wb.createSheet("题目数据文件");
//制作标题
s.addMergedRegion(new CellRangeAddress(1,1,1,12));
Row row_1 = s.createRow(1);
Cell cell_1_1 = row_1.createCell(1);
cell_1_1.setCellValue("在线试题导出信息");
//创建一个样式
CellStyle cs_title = wb.createCellStyle();
cs_title.setAlignment(HorizontalAlignment.CENTER);
cs_title.setVerticalAlignment(VerticalAlignment.CENTER);
cell_1_1.setCellStyle(cs_title);
//制作表头
//制作数据区
//创建一个文件对象，作为excel文件内容的输出文件
File f = new File("test.xlsx");
//输出时通过流的形式对外输出，包装对应的目标文件
OutputStream os = new FileOutputStream(f);
//将内存中的workbook数据写入到流中
wb.write(os);
wb.close();
os.close();
}
1.4 题目模板标题制作
下面我们接着来做Excel的表头
在测试方法testProjectPoi中继续编写代码
@Test
public void testProjectPoi() throws IOException {
//1.获取到对应的Excel文件，工作簿文件
Workbook wb = new XSSFWorkbook();
//2.创建工作表
Sheet s = wb.createSheet("题目数据文件");
//设置通用配置
// s.setColumnWidth(4,100);
//制作标题
s.addMergedRegion(new CellRangeAddress(1,1,1,12));
Row row_1 = s.createRow(1);
Cell cell_1_1 = row_1.createCell(1);
cell_1_1.setCellValue("在线试题导出信息");
//创建一个样式
CellStyle cs_title = wb.createCellStyle();
cs_title.setAlignment(HorizontalAlignment.CENTER);
cs_title.setVerticalAlignment(VerticalAlignment.CENTER);
cell_1_1.setCellStyle(cs_title);
//制作表头
String[] fields = {"题目ID","所属公司ID","所属目录ID","题目简介","题干描述",
"题干配图","题目分析","题目类型","题目难度","是否经典题","题目状态","审核状态"};
Row row_2 = s.createRow(2);
for (int i = 0; i < fields.length; i++) {
Cell cell_2_temp = row_2.createCell(1 + i); //++
cell_2_temp.setCellValue(fields[i]); //++
CellStyle cs_field = wb.createCellStyle();
cs_field.setAlignment(HorizontalAlignment.CENTER);
cell_2_temp.setCellStyle(cs_field);
}
//制作数据区
//创建一个文件对象，作为excel文件内容的输出文件
File f = new File("test.xlsx");
//输出时通过流的形式对外输出，包装对应的目标文件
OutputStream os = new FileOutputStream(f);
//将内存中的workbook数据写入到流中
wb.write(os);
wb.close();
os.close();
}
1.5 题目模板数据制作
我们继续来做数据区
@Test
public void testProjectPoi() throws IOException {
//1.获取到对应的Excel文件，工作簿文件
Workbook wb = new XSSFWorkbook();
//2.创建工作表
Sheet s = wb.createSheet("题目数据文件");
//设置通用配置
// s.setColumnWidth(4,100);
CellStyle cs_field = wb.createCellStyle();
cs_field.setAlignment(HorizontalAlignment.CENTER);
cs_field.setBorderTop(BorderStyle.THIN);
cs_field.setBorderBottom(BorderStyle.THIN);
cs_field.setBorderLeft(BorderStyle.THIN);
cs_field.setBorderRight(BorderStyle.THIN);
//制作标题
s.addMergedRegion(new CellRangeAddress(1,1,1,12));
Row row_1 = s.createRow(1);
Cell cell_1_1 = row_1.createCell(1);
cell_1_1.setCellValue("在线试题导出信息");
//创建一个样式
CellStyle cs_title = wb.createCellStyle();
cs_title.setAlignment(HorizontalAlignment.CENTER);
cs_title.setVerticalAlignment(VerticalAlignment.CENTER);
cell_1_1.setCellStyle(cs_title);
//制作表头
String[] fields = {"题目ID","所属公司ID","所属目录ID","题目简介","题干描述",
"题干配图","题目分析","题目类型","题目难度","是否经典题","题目状态","审核状态"};
Row row_2 = s.createRow(2);
for (int i = 0; i < fields.length; i++) {
Cell cell_2_temp = row_2.createCell(1 + i); //++
cell_2_temp.setCellValue(fields[i]); //++
cell_2_temp.setCellStyle(cs_field);
}
//制作数据区
List<Question> questionList = new ArrayList<>();
Question qq = new Question();
qq.setId("1");
qq.setPicture("12");
qq.setReviewStatus("13");
qq.setAnalysis("14");
qq.setCatalogId("15");
qq.setCompanyId("16");
qq.setDifficulty("17");
qq.setIsClassic("18");
qq.setRemark("19");
qq.setState("21");
qq.setSubject("31");
qq.setType("41");
questionList.add(qq);
Question qqq = new Question();
qqq.setId("1");
qqq.setPicture("12");
qqq.setReviewStatus("13");
qqq.setAnalysis("14");
qqq.setCatalogId("15");
qqq.setCompanyId("16");
qqq.setDifficulty("17");
qqq.setIsClassic("18");
qqq.setRemark("19");
qqq.setState("21");
qqq.setSubject("31");
qqq.setType("41");
questionList.add(qqq);
int row_index = 0;
for (Question q : questionList) {
int cell_index = 0;
Row row_temp = s.createRow(3 + row_index++);
Cell cell_data_1 = row_temp.createCell(1 + cell_index++);
cell_data_1.setCellValue(q.getId()); //++
cell_data_1.setCellStyle(cs_field);
Cell cell_data_2 = row_temp.createCell(1 + cell_index++);
cell_data_2.setCellValue(q.getCompanyId()); //++
cell_data_2.setCellStyle(cs_field);
Cell cell_data_3 = row_temp.createCell(1 + cell_index++);
cell_data_3.setCellValue(q.getCatalogId()); //++
cell_data_3.setCellStyle(cs_field);
Cell cell_data_4 = row_temp.createCell(1 + cell_index++);
cell_data_4.setCellValue(q.getRemark()); //++
cell_data_4.setCellStyle(cs_field);
Cell cell_data_5 = row_temp.createCell(1 + cell_index++);
cell_data_5.setCellValue(q.getSubject()); //++
cell_data_5.setCellStyle(cs_field);
Cell cell_data_6 = row_temp.createCell(1 + cell_index++);
cell_data_6.setCellValue(q.getPicture()); //++
cell_data_6.setCellStyle(cs_field);
Cell cell_data_7 = row_temp.createCell(1 + cell_index++);
cell_data_7.setCellValue(q.getAnalysis()); //++
cell_data_7.setCellStyle(cs_field);
Cell cell_data_8 = row_temp.createCell(1 + cell_index++);
cell_data_8.setCellValue(q.getType()); //++
cell_data_8.setCellStyle(cs_field);
Cell cell_data_9 = row_temp.createCell(1 + cell_index++);
cell_data_9.setCellValue(q.getDifficulty()); //++
cell_data_9.setCellStyle(cs_field);
Cell cell_data_10 = row_temp.createCell(1 + cell_index++);
cell_data_10.setCellValue(q.getIsClassic()); //++
cell_data_10.setCellStyle(cs_field);
Cell cell_data_11 = row_temp.createCell(1 + cell_index++);
cell_data_11.setCellValue(q.getState()); //++
cell_data_11.setCellStyle(cs_field);
Cell cell_data_12 = row_temp.createCell(1 + cell_index++);
cell_data_12.setCellValue(q.getReviewStatus()); //++
cell_data_12.setCellStyle(cs_field);
}
//创建一个文件对象，作为excel文件内容的输出文件
File f = new File("test.xlsx");
//输出时通过流的形式对外输出，包装对应的目标文件
OutputStream os = new FileOutputStream(f);
//将内存中的workbook数据写入到流中
wb.write(os);
wb.close();
os.close();
}
1.6 题目报表数据准备
（1）找到/WEB-INF/pages/store/question/list.jsp页面，修改导出题目的链接
<button type="button" class="btn btn-default" title="导出题目" onclick=location.href="${ctx}/store/question?operation=downloadReport"> <i class="fa fa-download"></i>导出题目</button>
（2）在后台servlet中添加对应的方法
// uri:/store/question?operation=list
@WebServlet("/store/question")
public class QuestionServlet extends BaseServlet {
@Override
protected void doGet(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException {
String operation = request.getParameter("operation");
if("list".equals(operation)){
this.list(request,response);
}
//其他的else if判断省略
else if("downloadReport".equals(operation)){
this.downloadReport(request,response);
}
}
private void downloadReport(HttpServletRequest request, HttpServletResponse response) throws IOException {
//生成报告的文件，然后传递到前端页面
questionService.getReport();
}
}
（3）在业务层QuestionService添加一个方法getReport
public void getReport() throws IOException;
（4）在对应的实现类中去实现该方法，把之前在测试类中的测试方法testProjectPoi里面的所有代码拷贝过来，其中数据我们应该是从数据库中查询出来，因此调用dao完成数据的查询
@Override
public void getReport() throws IOException{
//获取对应要展示的数据
SqlSession sqlSession = null;
List<Question> questionList = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
QuestionDao questionDao = MapperFactory.getMapper(sqlSession,QuestionDao.class);
//3.调用Dao层操作
questionList = questionDao.findAll();
}catch (Exception e){
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
//1.获取到对应的Excel文件，工作簿文件
Workbook wb = new XSSFWorkbook();
//2.创建工作表
Sheet s = wb.createSheet("题目数据文件");
//设置通用配置
// s.setColumnWidth(4,100);
CellStyle cs_field = wb.createCellStyle();
cs_field.setAlignment(HorizontalAlignment.CENTER);
cs_field.setBorderTop(BorderStyle.THIN);
cs_field.setBorderBottom(BorderStyle.THIN);
cs_field.setBorderLeft(BorderStyle.THIN);
cs_field.setBorderRight(BorderStyle.THIN);
//制作标题
s.addMergedRegion(new CellRangeAddress(1,1,1,12));
Row row_1 = s.createRow(1);
Cell cell_1_1 = row_1.createCell(1);
cell_1_1.setCellValue("在线试题导出信息");
//创建一个样式
CellStyle cs_title = wb.createCellStyle();
cs_title.setAlignment(HorizontalAlignment.CENTER);
cs_title.setVerticalAlignment(VerticalAlignment.CENTER);
cell_1_1.setCellStyle(cs_title);
//制作表头
String[] fields = {"题目ID","所属公司ID","所属目录ID","题目简介","题干描述",
"题干配图","题目分析","题目类型","题目难度","是否经典题","题目状态","审核状态"};
Row row_2 = s.createRow(2);
for (int i = 0; i < fields.length; i++) {
Cell cell_2_temp = row_2.createCell(1 + i); //++
cell_2_temp.setCellValue(fields[i]); //++
cell_2_temp.setCellStyle(cs_field);
}
//制作数据区
int row_index = 0;
for (Question q : questionList) {
int cell_index = 0;
Row row_temp = s.createRow(3 + row_index++);
Cell cell_data_1 = row_temp.createCell(1 + cell_index++);
cell_data_1.setCellValue(q.getId()); //++
cell_data_1.setCellStyle(cs_field);
Cell cell_data_2 = row_temp.createCell(1 + cell_index++);
cell_data_2.setCellValue(q.getCompanyId()); //++
cell_data_2.setCellStyle(cs_field);
Cell cell_data_3 = row_temp.createCell(1 + cell_index++);
cell_data_3.setCellValue(q.getCatalogId()); //++
cell_data_3.setCellStyle(cs_field);
Cell cell_data_4 = row_temp.createCell(1 + cell_index++);
cell_data_4.setCellValue(q.getRemark()); //++
cell_data_4.setCellStyle(cs_field);
Cell cell_data_5 = row_temp.createCell(1 + cell_index++);
cell_data_5.setCellValue(q.getSubject()); //++
cell_data_5.setCellStyle(cs_field);
Cell cell_data_6 = row_temp.createCell(1 + cell_index++);
cell_data_6.setCellValue(q.getPicture()); //++
cell_data_6.setCellStyle(cs_field);
Cell cell_data_7 = row_temp.createCell(1 + cell_index++);
cell_data_7.setCellValue(q.getAnalysis()); //++
cell_data_7.setCellStyle(cs_field);
Cell cell_data_8 = row_temp.createCell(1 + cell_index++);
cell_data_8.setCellValue(q.getType()); //++
cell_data_8.setCellStyle(cs_field);
Cell cell_data_9 = row_temp.createCell(1 + cell_index++);
cell_data_9.setCellValue(q.getDifficulty()); //++
cell_data_9.setCellStyle(cs_field);
Cell cell_data_10 = row_temp.createCell(1 + cell_index++);
cell_data_10.setCellValue(q.getIsClassic()); //++
cell_data_10.setCellStyle(cs_field);
Cell cell_data_11 = row_temp.createCell(1 + cell_index++);
cell_data_11.setCellValue(q.getState()); //++
cell_data_11.setCellStyle(cs_field);
Cell cell_data_12 = row_temp.createCell(1 + cell_index++);
cell_data_12.setCellValue(q.getReviewStatus()); //++
cell_data_12.setCellStyle(cs_field);
}
//创建一个文件对象，作为excel文件内容的输出文件
File f = new File("test.xlsx");
//输出时通过流的形式对外输出，包装对应的目标文件
OutputStream os = new FileOutputStream(f);
//将内存中的workbook数据写入到流中
wb.write(os);
wb.close();
os.close();
}
1.7 题目报表业务实现
现在后台已经能够生成Excel文件并且填充了数据，但是真实的业务中我们是需要将这个文件下载到客户端
（1）修改接口方法getReport，添加返回值
/**
* 获取包含了数据的流对象
* @return 包含了报表数据的流对象
* @throws IOException
*/
ByteArrayOutputStream getReport() throws IOException;
（2）在实现类中实现该方法时，将内存中的Excel相关数据写入到ByteArrayOutputStream流中
@Override
public ByteArrayOutputStream getReport() throws IOException {
//前面的代码无变动 故省略
/**
//创建一个文件对象，作为excel文件内容的输出文件
File f = new File("test.xlsx");
//输出时通过流的形式对外输出，包装对应的目标文件
OutputStream os = new FileOutputStream(f);
//将内存中的workbook数据写入到流中
wb.write(os);
wb.close();
os.close();
*/
//将内存中的workbook数据写入到流中
ByteArrayOutputStream os = new ByteArrayOutputStream();
wb.write(os);
wb.close();
return os;
}
（3）修改后台servlet的downloadReport方法
private void downloadReport(HttpServletRequest request, HttpServletResponse response) throws IOException {
//返回的数据类型为文件xlsx类型
response.setContentType("application/vnd.openxmlformats-officedocument.spreadsheetml.sheet;charset=utf-8");
String fileName = new String("测试文件名.xlsx".getBytes(),"iso8859-1");
response.addHeader("Content-Disposition","attachment;fileName="+fileName);
//生成报告的文件，然后传递到前端页面
ByteArrayOutputStream os = questionService.getReport();
//获取产生响应的流对象
ServletOutputStream sos = response.getOutputStream();
//将数据从原始的字节流对象中提取出来写入到servlet对应的输出流中
os.writeTo(sos);
//将输出流刷新
sos.flush();
os.close();
}
2.权限系统设计与开发
2.1 权限系统简介与结构设计
什么是权限系统？
权限系统是一种设定用户与可操作模块之间关系的系统。
通过设定用户与可操作的模块之间的关系,控制用户在可指定范围内进行业务执行
基于用户的权限控制(UBAC:User-BasedAccessControl)
基于角色的权限控制(RBAC:role-BasedAccessControl)
在本课程中我们采用基于角色的权限控制RBAC
2.2 角色与模块功能快速开发
首先来看角色与模块各自的结构
（1）创建角色实体：com.itheima.domain.system.Role
public class Role {
private String id;
private String name;
private String remark;
private Date createTime;
// getter/setter略
}
（2）创建角色Dao：com.itheima.dao.system.RoleDao
public interface RoleDao {
int save(Role role);
int delete(Role role);
int update(Role role);
Role findById(String id);
List<Role> findAll();
}
（3）添加接口的映射配置文件，从今日课程资料中找到资料\dao层资源文件将里面所有的xml映射配置文件拷贝到项目src/main/resources/com/itheima/dao/system目录下
（4）创建业务层接口：com.itheima.service.system.RoleService
public interface RoleService {
/**
* 添加
* @param role
* @return
*/
void save(Role role);
/**
* 删除
* @param role
* @return
*/
void delete(Role role);
/**
* 修改
* @param role
* @return
*/
void update(Role role);
/**
* 查询单个
* @param id 查询的条件（id）
* @return 查询的结果，单个对象
*/
Role findById(String id);
/**
* 查询全部的数据
* @return 全部数据的列表对象
*/
List<Role> findAll();
/**
* 分页查询数据
* @param page 页码
* @param size 每页显示的数据总量
* @return
*/
PageInfo findAll(int page, int size);
}
（5）创建接口的实现：com.itheima.service.system.impl
public class RoleServiceImpl implements RoleService {
@Override
public void save(Role role) {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
RoleDao roleDao = MapperFactory.getMapper(sqlSession,RoleDao.class);
//id使用UUID的生成策略来获取
String id = UUID.randomUUID().toString();
role.setId(id);
//3.调用Dao层操作
roleDao.save(role);
//4.提交事务
TransactionUtil.commit(sqlSession);
}catch (Exception e){
TransactionUtil.rollback(sqlSession);
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
@Override
public void delete(Role role) {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
RoleDao roleDao = MapperFactory.getMapper(sqlSession,RoleDao.class);
//3.调用Dao层操作
roleDao.delete(role);
//4.提交事务
TransactionUtil.commit(sqlSession);
}catch (Exception e){
TransactionUtil.rollback(sqlSession);
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
@Override
public void update(Role role) {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
RoleDao roleDao = MapperFactory.getMapper(sqlSession,RoleDao.class);
//3.调用Dao层操作
roleDao.update(role);
//4.提交事务
TransactionUtil.commit(sqlSession);
}catch (Exception e){
TransactionUtil.rollback(sqlSession);
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
@Override
public Role findById(String id) {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
RoleDao roleDao = MapperFactory.getMapper(sqlSession,RoleDao.class);
//3.调用Dao层操作
return roleDao.findById(id);
}catch (Exception e){
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
@Override
public List<Role> findAll() {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
RoleDao roleDao = MapperFactory.getMapper(sqlSession,RoleDao.class);
//3.调用Dao层操作
return roleDao.findAll();
}catch (Exception e){
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
@Override
public PageInfo findAll(int page, int size) {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
RoleDao roleDao = MapperFactory.getMapper(sqlSession,RoleDao.class);
//3.调用Dao层操作
PageHelper.startPage(page,size);
List<Role> all = roleDao.findAll();
PageInfo pageInfo = new PageInfo(all);
return pageInfo;
}catch (Exception e){
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
}
（6）创建sevlet：com.itheima.web.controller.system.RoleServlet
// uri:/system/role?operation=list
@WebServlet("/system/role")
public class RoleServlet extends BaseServlet {
@Override
protected void doGet(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException {
String operation = request.getParameter("operation");
if("list".equals(operation)){
this.list(request,response);
}else if("toAdd".equals(operation)){
this.toAdd(request,response);
}else if("save".equals(operation)){
this.save(request, response);
}else if("toEdit".equals(operation)){
this.toEdit(request,response);
}else if("edit".equals(operation)){
this.edit(request,response);
}else if("delete".equals(operation)){
this.delete(request,response);
}else if("author".equals(operation)){
this.author(request,response);
}
}
private void list(HttpServletRequest request,HttpServletResponse response) throws ServletException, IOException {
//进入列表页
//获取数据
int page = 1;
int size = 5;
if(StringUtils.isNotBlank(request.getParameter("page"))){
page = Integer.parseInt(request.getParameter("page"));
}
if(StringUtils.isNotBlank(request.getParameter("size"))){
size = Integer.parseInt(request.getParameter("size"));
}
PageInfo all = roleService.findAll(page, size);
//将数据保存到指定的位置
request.setAttribute("page",all);
//跳转页面
request.getRequestDispatcher("/WEB-INF/pages/system/role/list.jsp").forward(request,response);
}
private void toAdd(HttpServletRequest request,HttpServletResponse response) throws ServletException, IOException {
//加载所有的部门信息放入到roleList
List<Role> all = roleService.findAll();
request.setAttribute("roleList",all);
//跳转页面
request.getRequestDispatcher("/WEB-INF/pages/system/role/add.jsp").forward(request,response);
}
private void save(HttpServletRequest request,HttpServletResponse response) throws ServletException, IOException {
//将数据获取到，封装成一个对象
Role role = BeanUtil.fillBean(request,Role.class,"yyyy-MM-dd");
//调用业务层接口save
roleService.save(role);
//跳转回到页面list
response.sendRedirect(request.getContextPath()+"/system/role?operation=list");
}
private void toEdit(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException {
//查询要修改的数据findById
String id = request.getParameter("id");
Role role = roleService.findById(id);
//将数据加载到指定区域，供页面获取
request.setAttribute("role",role);
//跳转页面
request.getRequestDispatcher("/WEB-INF/pages/system/role/update.jsp").forward(request,response);
}
private void edit(HttpServletRequest request, HttpServletResponse response) throws IOException {
//将数据获取到，封装成一个对象
Role role = BeanUtil.fillBean(request,Role.class,"yyyy-MM-dd");
//调用业务层接口save
roleService.update(role);
//跳转回到页面list
response.sendRedirect(request.getContextPath()+"/system/role?operation=list");
}
private void delete(HttpServletRequest request, HttpServletResponse response) throws IOException {
//将数据获取到，封装成一个对象
Role role = BeanUtil.fillBean(request,Role.class);
//调用业务层接口save
roleService.delete(role);
//跳转回到页面list
response.sendRedirect(request.getContextPath()+"/system/role?operation=list");
}
private void author(HttpServletRequest request, HttpServletResponse response) throws IOException, ServletException {
//获取要授权的角色id
String roleId = request.getParameter("id");
//使用id查询对应的数据（角色id对应的模块信息）
Role role = roleService.findById(roleId);
request.setAttribute("role",role);
//根据当前的角色id获取所有的模块数据，并加载关系数据
List<Map> map = moduleService.findAuthorDataByRoleId(roleId);
//map转成json数据
ObjectMapper om = new ObjectMapper();
String json = om.writeValueAsString(map);
request.setAttribute("roleModuleJson",json);
// TODO 数据未查询
//跳转到树页面中
request.getRequestDispatcher("/WEB-INF/pages/system/role/author.jsp").forward(request,response);
}
@Override
protected void doPost(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException {
this.doGet(request,response);
}
}
同时需要在BaseServlet中添加RoleService
public class BaseServlet extends HttpServlet {
protected CompanyService companyService;
protected DeptService deptService;
protected UserService userService;
protected CourseService courseService;
protected CatalogService catalogService;
protected QuestionService questionService;
protected QuestionItemService questionItemService;
protected RoleService roleService;
@Override
public void init() throws ServletException {
companyService = new CompanyServiceImpl();
deptService = new DeptServiceImpl();
userService = new UserServiceImpl();
courseService = new CourseServiceImpl();
catalogService = new CatalogServiceImpl();
questionService = new QuestionServiceImpl();
questionItemService = new QuestionItemServiceImpl();
roleService = new RoleServiceImpl();
}
}
（7）拷贝页面到项目中，从今日课程资料中找到：资料\模块页面将下面所有模块全部拷贝到项目/WEB-INF/pages/system目录下
（8）启动项目，进行测试
然后我们按照相同的方式将模块的相关功能快速开发完成
（1）创建模块实体：com.itheima.domain.system.Module
public class Module {
private String id;
private String parentId;
private String name;
private Long ctype;
private Long state;
private String curl;
private String remark;
private Module module;
// getter/setter略
}
（2）创建模块dao：com.itheima.dao.system.ModuleDao
public interface ModuleDao {
int save(Module module);
int delete(Module module);
int update(Module module);
Module findById(String id);
List<Module> findAll();
}
（3）映射配置文件，之前已拷贝，查看一下即可
（4）创建业务层接口：com.itheima.service.system.ModuleService
public interface ModuleService {
/**
* 添加
* @param module
* @return
*/
void save(Module module);
/**
* 删除
* @param module
* @return
*/
void delete(Module module);
/**
* 修改
* @param module
* @return
*/
void update(Module module);
/**
* 查询单个
* @param id 查询的条件（id）
* @return 查询的结果，单个对象
*/
Module findById(String id);
/**
* 查询全部的数据
* @return 全部数据的列表对象
*/
List<Module> findAll();
/**
* 分页查询数据
* @param page 页码
* @param size 每页显示的数据总量
* @return
*/
PageInfo findAll(int page, int size);
}
（5）创建业务层实现类：com.itheima.service.system.impl.ModuleServiceImpl
public class ModuleServiceImpl implements ModuleService {
@Override
public void save(Module module) {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
ModuleDao moduleDao = MapperFactory.getMapper(sqlSession,ModuleDao.class);
//id使用UUID的生成策略来获取
String id = UUID.randomUUID().toString();
module.setId(id);
//3.调用Dao层操作
moduleDao.save(module);
//4.提交事务
TransactionUtil.commit(sqlSession);
}catch (Exception e){
TransactionUtil.rollback(sqlSession);
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
@Override
public void delete(Module module) {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
ModuleDao moduleDao = MapperFactory.getMapper(sqlSession,ModuleDao.class);
//3.调用Dao层操作
moduleDao.delete(module);
//4.提交事务
TransactionUtil.commit(sqlSession);
}catch (Exception e){
TransactionUtil.rollback(sqlSession);
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
@Override
public void update(Module module) {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
ModuleDao moduleDao = MapperFactory.getMapper(sqlSession,ModuleDao.class);
//3.调用Dao层操作
moduleDao.update(module);
//4.提交事务
TransactionUtil.commit(sqlSession);
}catch (Exception e){
TransactionUtil.rollback(sqlSession);
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
@Override
public Module findById(String id) {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
ModuleDao moduleDao = MapperFactory.getMapper(sqlSession,ModuleDao.class);
//3.调用Dao层操作
return moduleDao.findById(id);
}catch (Exception e){
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
@Override
public List<Module> findAll() {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
ModuleDao moduleDao = MapperFactory.getMapper(sqlSession,ModuleDao.class);
//3.调用Dao层操作
return moduleDao.findAll();
}catch (Exception e){
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
@Override
public PageInfo findAll(int page, int size) {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
ModuleDao moduleDao = MapperFactory.getMapper(sqlSession,ModuleDao.class);
//3.调用Dao层操作
PageHelper.startPage(page,size);
List<Module> all = moduleDao.findAll();
PageInfo pageInfo = new PageInfo(all);
return pageInfo;
}catch (Exception e){
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
}
（6）创建servlet：com.itheima.web.controller.system.ModuleServlet
// uri:/system/module?operation=list
@WebServlet("/system/module")
public class ModuleServlet extends BaseServlet {
@Override
protected void doGet(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException {
String operation = request.getParameter("operation");
if("list".equals(operation)){
this.list(request,response);
}else if("toAdd".equals(operation)){
this.toAdd(request,response);
}else if("save".equals(operation)){
this.save(request, response);
}else if("toEdit".equals(operation)){
this.toEdit(request,response);
}else if("edit".equals(operation)){
this.edit(request,response);
}else if("delete".equals(operation)){
this.delete(request,response);
}
}
private void list(HttpServletRequest request,HttpServletResponse response) throws ServletException, IOException {
//进入列表页
//获取数据
int page = 1;
int size = 10;
if(StringUtils.isNotBlank(request.getParameter("page"))){
page = Integer.parseInt(request.getParameter("page"));
}
if(StringUtils.isNotBlank(request.getParameter("size"))){
size = Integer.parseInt(request.getParameter("size"));
}
PageInfo all = moduleService.findAll(page, size);
//将数据保存到指定的位置
request.setAttribute("page",all);
//跳转页面
request.getRequestDispatcher("/WEB-INF/pages/system/module/list.jsp").forward(request,response);
}
private void toAdd(HttpServletRequest request,HttpServletResponse response) throws ServletException, IOException {
//加载所有的信息放入到moduleList
List<Module> all = moduleService.findAll();
request.setAttribute("moduleList",all);
//跳转页面
request.getRequestDispatcher("/WEB-INF/pages/system/module/add.jsp").forward(request,response);
}
private void save(HttpServletRequest request,HttpServletResponse response) throws ServletException, IOException {
//将数据获取到，封装成一个对象
Module module = BeanUtil.fillBean(request,Module.class,"yyyy-MM-dd");
//调用业务层接口save
moduleService.save(module);
//跳转回到页面list
response.sendRedirect(request.getContextPath()+"/system/module?operation=list");
}
private void toEdit(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException {
//查询要修改的数据findById
String id = request.getParameter("id");
Module module = moduleService.findById(id);
//将数据加载到指定区域，供页面获取
request.setAttribute("module",module);
//跳转页面
request.getRequestDispatcher("/WEB-INF/pages/system/module/update.jsp").forward(request,response);
}
private void edit(HttpServletRequest request, HttpServletResponse response) throws IOException {
//将数据获取到，封装成一个对象
Module module = BeanUtil.fillBean(request,Module.class,"yyyy-MM-dd");
//调用业务层接口save
moduleService.update(module);
//跳转回到页面list
response.sendRedirect(request.getContextPath()+"/system/module?operation=list");
}
private void delete(HttpServletRequest request, HttpServletResponse response) throws IOException {
//将数据获取到，封装成一个对象
Module module = BeanUtil.fillBean(request,Module.class);
//调用业务层接口save
moduleService.delete(module);
//跳转回到页面list
response.sendRedirect(request.getContextPath()+"/system/module?operation=list");
}
@Override
protected void doPost(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException {
this.doGet(request,response);
}
}
同时需要在BserServlet中添加ModuleService
public class BaseServlet extends HttpServlet {
protected CompanyService companyService;
protected DeptService deptService;
protected UserService userService;
protected CourseService courseService;
protected CatalogService catalogService;
protected QuestionService questionService;
protected QuestionItemService questionItemService;
protected RoleService roleService;
protected ModuleService moduleService;
@Override
public void init() throws ServletException {
companyService = new CompanyServiceImpl();
deptService = new DeptServiceImpl();
userService = new UserServiceImpl();
courseService = new CourseServiceImpl();
catalogService = new CatalogServiceImpl();
questionService = new QuestionServiceImpl();
questionItemService = new QuestionItemServiceImpl();
roleService = new RoleServiceImpl();
moduleService = new ModuleServiceImpl();
}
}
（7）拷贝页面：之前已经拷贝过了，我们可以直接启动项目进行测试！
2.3 树形控件结构分析（1）
树形结构如下图所示：
对应的实现技术有：
dTree
tdTree
zTree
我们主要来看关于zTree的相关操作，从今日课程资料中找到：资料\树\zTree-zTree_v3-master\zTree_v3\demo\cn\index.html，打开就可查阅
我们主要是针对里面的Checkbox 勾选操作进行学习，我们自己来编写一个测试页面test.html来完成一个树形结构，操作步骤：
- 1.观察整体的页面结构
- 2.去除无效的基础信息
- 3.去除页面无效的基础信息
- 4.分析页面js内容
- 5.分页结构所使用的数据
- 6.简化页面内容书写 ```html
- 1.观察整体的页面结构
- 2.去除无效的基础信息
- 3.去除页面无效的基础信息
- 4.分析页面js内容
- 5.分页结构所使用的数据
- 6.简化页面内容书写
<ul id="treeDemo" class="ztree"></ul><ul class="info"> <li class="title"> <ul class="list"> <li> <input type="checkbox" id="py" class="checkbox first" checked /><span>关联父</span> <input type="checkbox" id="sy" class="checkbox first" checked /><span>关联子</span><br/> <input type="checkbox" id="pn" class="checkbox first" checked /><span>关联父</span> <input type="checkbox" id="sn" class="checkbox first" checked /><span>关联子</span><br/> <ul id="code" class="log" style="height:20px;"></ul></p> </li> </ul> </li>
2.4 树形控件结构分析（2）
分析页面js ```html<a name="XPIPT"></a>
### 2.5 树形控件结构分析（3）
继续进行数据结构的分析
```html
<meta http-equiv="content-type" content="text/html; charset=UTF-8">
<link rel="stylesheet" href="../../../css/demo.css" type="text/css">
<link rel="stylesheet" href="../../../css/zTreeStyle/zTreeStyle.css" type="text/css">
<script type="text/javascript" src="../../../js/jquery-1.4.4.min.js"></script>
<script type="text/javascript" src="../../../js/jquery.ztree.core-3.5.js"></script>
<script type="text/javascript" src="../../../js/jquery.ztree.excheck-3.5.js"></script>
<SCRIPT type="text/javascript">
var setting = {check: {enable: true},data: { simpleData: {enable: true}}};
var zNodes =[
{ id:2, pId:0, name:"test", checked:true, open:true},
{ id:21, pId:2, name:"test22222"},
{ id:22, pId:1, name:"test22222"}
];
$(document).ready(function(){
$.fn.zTree.init($("#treeDemo"), setting, zNodes);
var zTree = $.fn.zTree.getZTreeObj("treeDemo")
zTree.setting.check.chkboxType = { "Y" : "ps", "N" : "ps" }
});
</SCRIPT>
<ul id="treeDemo" class="ztree"></ul>
2.6 动态加载授权数据
（1）查看页面：/WEB-INF/pages/system/role/list.jsp，授权按钮点击时要传递id（2）进入后台servlet：
RoleServlet添加author方法@Override
protected void doGet(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException {
String operation = request.getParameter("operation");
if("list".equals(operation)){
this.list(request,response);
}else if("toAdd".equals(operation)){
this.toAdd(request,response);
}else if("save".equals(operation)){
this.save(request, response);
}else if("toEdit".equals(operation)){
this.toEdit(request,response);
}else if("edit".equals(operation)){
this.edit(request,response);
}else if("delete".equals(operation)){
this.delete(request,response);
}else if("author".equals(operation)){
this.author(request,response);
}
}
private void author(HttpServletRequest request, HttpServletResponse response) throws IOException, ServletException {
//获取要授权的角色id
String roleId = request.getParameter("id");
// TODO 数据未查询
//跳转到树页面中
request.getRequestDispatcher("/WEB-INF/pages/system/role/author.jsp").forward(request,response);
}
/WEB-INF/pages/system/role下创建一个jsp页面：test.jsp，内容粘贴我们之前编辑的test.html页面，我们在后台跳转的时候跳转的是该目录下的author.jsp，我们可以拿这俩页面做一个对比（4）完善servlet中的
author方法private void author(HttpServletRequest request, HttpServletResponse response) throws IOException, ServletException {
//获取要授权的角色id
String roleId = request.getParameter("id");
//使用id查询对应的数据（角色id对应的模块信息）
Role role = roleService.findById(roleId);
request.setAttribute("role",role);
//根据当前的角色id获取所有的模块数据，并加载关系数据
List<Map> map = moduleService.findAuthorDataByRoleId(roleId);
//map转成json数据
ObjectMapper om = new ObjectMapper();
String json = om.writeValueAsString(map);
request.setAttribute("roleModuleJson",json);
// TODO 数据未查询
//跳转到树页面中
request.getRequestDispatcher("/WEB-INF/pages/system/role/author.jsp").forward(request,response);
}
WEB-INF\pages\system\role\author.jsp页面中修改js代码：用后台查询的数据直接赋值给zNodesvar zNodes =${roleModuleJson}
ModuleService中添加findAuthorDataByRoleId方法/**
* 根据角色id获取对应的所有模块关联数据
* @param roleId 角色id
*/
List<Map> findAuthorDataByRoleId(String roleId);
@Override
public List<Map> findAuthorDataByRoleId(String roleId) {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
ModuleDao moduleDao = MapperFactory.getMapper(sqlSession,ModuleDao.class);
//3.调用Dao层操作
return moduleDao.findAuthorDataByRoleId(roleId);
}catch (Exception e){
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
findAuthorDataByRoleIdList<Map> findAuthorDataByRoleId(String roleId);
<select id="findAuthorDataByRoleId" parameterType="string" resultType="java.util.Map">
select
module_id as id,
parent_id as pId,
name as name,
case
when module_id in (select module_id from ss_role_module where role_id = #{roleId})
then 'true'
else 'false'
end
as checked
from
ss_module
</select>
2.7 绑定角色与模块关系
（1）查看WEB-INF\pages\system\role\author.jsp页面中提交保存的js代码<SCRIPT type="text/javascript">
//实现权限分配
function submitCheckedNodes() {
//1.获取所有的勾选权限节点
var nodes = zTreeObj.getCheckedNodes(true);//true:被勾选，false：未被勾选
//2.循环nodes，获取每个节点的id，并将数据加入数组
//1,2,3,4,5 1+","+2+","+3.....
//数据的临时存储数组，为了方便内容连接成为一个由逗号分隔的字符串
var moduleArrays = [];
for(var i=0;i<nodes.length;i++) {
moduleArrays.push(nodes[i].id);
}
//3.将数组中的数据使用,连接后，赋值给表单，传入后台
$("#moduleIds").val(moduleArrays.join(',')); //1,2,3,4,5
$("#icform").submit();
}
</SCRIPT>
<form id="icform" method="post" action="${ctx}/system/role?operation=updateRoleModule">
<input type="hidden" name="roleId" value="${role.id}"/>
<input type="hidden" id="moduleIds" name="moduleIds" value=""/>
<ul id="treeDemo" class="ztree"></ul>
</form>
<!--工具栏-->
</form>
updateRoleModule@Override
protected void doGet(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException {
String operation = request.getParameter("operation");
if("list".equals(operation)){
this.list(request,response);
}
//中间的else if无变动 省略
else if("updateRoleModule".equals(operation)){
this.updateRoleModule(request,response);
}
}
private void updateRoleModule(HttpServletRequest request, HttpServletResponse response) throws IOException, ServletException {
String roleId = request.getParameter("roleId");
String moduleIds = request.getParameter("moduleIds");
roleService.updateRoleModule(roleId,moduleIds);
//跳转回到页面list
response.sendRedirect(request.getContextPath()+"/system/role?operation=list");
}
RoleService中添加方法updateRoleModule/**
* 建立角色与模块之间的关联
* @param roleId 角色id
* @param moduleIds 模块id（多个）
*/
void updateRoleModule(String roleId, String moduleIds);
@Override
public void updateRoleModule(String roleId, String moduleIds) {
SqlSession sqlSession = null;
try{
//1.获取SqlSession
sqlSession = MapperFactory.getSqlSession();
//2.获取Dao
RoleDao roleDao = MapperFactory.getMapper(sqlSession,RoleDao.class);
//3.调用Dao层操作
//修改role_module
//3.1现有的关系全部取消掉
roleDao.deleteRoleModule(roleId);
//3.2建立新的关系（多个）
String[] moduleArray = moduleIds.split(",");
for(String moduleId:moduleArray){
roleDao.saveRoleModule(roleId,moduleId);
}
//4.提交事务
TransactionUtil.commit(sqlSession);
}catch (Exception e){
TransactionUtil.rollback(sqlSession);
throw new RuntimeException(e);
//记录日志
}finally {
try {
TransactionUtil.close(sqlSession);
}catch (Exception e){
e.printStackTrace();
}
}
}
RoleDao中添加方法deleteRoleModule，saveRoleModulevoid deleteRoleModule(String roleId);
void saveRoleModule(@Param("roleId") String roleId, @Param("moduleId") String moduleId);
<!--配置根据roleId删除关系表数据-->
<delete id="deleteRoleModule" parameterType="java.lang.String">
delete from ss_role_module
where role_id = #{roleId,jdbcType=VARCHAR}
</delete>
<!--配置全字段插入，当某个字段没有值时，插入null-->
<insert id="saveRoleModule" parameterType="map">
insert into ss_role_module (role_id, module_id)
values (#{roleId,jdbcType=VARCHAR}, #{moduleId,jdbcType=VARCHAR})
</insert>
若有收获，就点个赞吧
0 人点赞
