1.创建docker上下文
mkdir -p /Users/zenghui/Desktop/Docker/mycat/master1
mkdir -p /Users/zenghui/Desktop/Docker/mycat/master2
mkdir -p /Users/zenghui/Desktop/Docker/mycat/slave1
mkdir -p /Users/zenghui/Desktop/Docker/mycat/slave2
mkdir -p /Users/zenghui/Desktop/Docker/mycat/mycat/conf
cd /Users/zenghui/Desktop/Docker/mycat
下载mycat安装包到路径下
http://dl.mycat.org.cn/1.6-RELEASE/Mycat-server-1.6-RELEASE-20161028204710-linux.tar.gz
2.Dockerfile文件配置
vi Dockerfile
FROM centos:7WORKDIR /COPY Mycat-server-1.6-RELEASE-20161028204710-linux.tar.gz Mycat-server-1.6-RELEASE-20161028204710-linux.tar.gzRUN tar zxf Mycat-server-1.6-RELEASE-20161028204710-linux.tar.gz -C /usr/local/
3.docker-compose文件配置
vi docker-compose.yml
version: "3.9"
services:
mysql-master1:
image: mysql:5.7
environment:
- MYSQL_ROOT_PASSWORD=123456
ports:
- "3333:3306"
volumes:
- "/Users/zenghui/Desktop/Docker/mycat/master1/my.cnf:/etc/mysql/conf.d/my.cnf"
mysql-master2:
image: mysql:5.7
environment:
- MYSQL_ROOT_PASSWORD=123456
ports:
- "3334:3306"
volumes:
- "/Users/zenghui/Desktop/Docker/mycat/master2/my.cnf:/etc/mysql/conf.d/my.cnf"
mysql-slave1:
image: mysql:5.7
environment:
- MYSQL_ROOT_PASSWORD=123456
ports:
- "3335:3306"
volumes:
- "/Users/zenghui/Desktop/Docker/mycat/slave1/my.cnf:/etc/mysql/conf.d/my.cnf"
depends_on:
- mysql-master1
links:
- mysql-master1
mysql-slave2:
image: mysql:5.7
environment:
- MYSQL_ROOT_PASSWORD=123456
ports:
- "3336:3306"
volumes:
- "/Users/zenghui/Desktop/Docker/mycat/slave2/my.cnf:/etc/mysql/conf.d/my.cnf"
depends_on:
- mysql-master2
links:
- mysql-master2
mycat:
build: .
ports:
- "8066:8066"
volumes:
- "/Users/zenghui/Desktop/Docker/mycat/mycat/conf/server.xml:/usr/local/mycat/conf/server.xml"
- "/Users/zenghui/Desktop/Docker/mycat/mycat/conf/schema.xml:/usr/local/mycat/conf/schema.xml"
depends_on:
- mysql-master1
- mysql-master2
- mysql-slave1
- mysql-slave2
links:
- mysql-master1
- mysql-master2
- mysql-slave1
- mysql-slave2
stdin_open: true
tty: true
4.server.xml编辑
vi /Users/zenghui/Desktop/Docker/mycat/mycat/conf/server.xml
<?xml version="1.0" encoding="UTF-8"?>
<!-- - - Licensed under the Apache License, Version 2.0 (the "License");
- you may not use this file except in compliance with the License. - You
may obtain a copy of the License at - - http://www.apache.org/licenses/LICENSE-2.0
- - Unless required by applicable law or agreed to in writing, software -
distributed under the License is distributed on an "AS IS" BASIS, - WITHOUT
WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. - See the
License for the specific language governing permissions and - limitations
under the License. -->
<!DOCTYPE mycat:server SYSTEM "server.dtd">
<mycat:server xmlns:mycat="http://io.mycat/">
<system>
<property name="useSqlStat">0</property> <!-- 1为开启实时统计、0为关闭 -->
<property name="useGlobleTableCheck">0</property> <!-- 1为开启全加班一致性检测、0为关闭 -->
<property name="sequnceHandlerType">2</property>
<!-- <property name="useCompression">1</property>--> <!--1为开启mysql压缩协议-->
<!-- <property name="fakeMySQLVersion">5.6.20</property>--> <!--设置模拟的MySQL版本号-->
<!-- <property name="processorBufferChunk">40960</property> -->
<!--
<property name="processors">1</property>
<property name="processorExecutor">32</property>
-->
<!--默认为type 0: DirectByteBufferPool | type 1 ByteBufferArena-->
<property name="processorBufferPoolType">0</property>
<!--默认是65535 64K 用于sql解析时最大文本长度 -->
<!--<property name="maxStringLiteralLength">65535</property>-->
<!--<property name="sequnceHandlerType">0</property>-->
<!--<property name="backSocketNoDelay">1</property>-->
<!--<property name="frontSocketNoDelay">1</property>-->
<!--<property name="processorExecutor">16</property>-->
<!--
<property name="serverPort">8066</property> <property name="managerPort">9066</property>
<property name="idleTimeout">300000</property> <property name="bindIp">0.0.0.0</property>
<property name="frontWriteQueueSize">4096</property> <property name="processors">32</property> -->
<!--分布式事务开关，0为不过滤分布式事务，1为过滤分布式事务（如果分布式事务内只涉及全局表，则不过滤），2为不过滤分布式事务,但是记录分布式事务日志-->
<property name="handleDistributedTransactions">0</property>
<!--
off heap for merge/order/group/limit 1开启 0关闭
-->
<property name="useOffHeapForMerge">1</property>
<!--
单位为m
-->
<property name="memoryPageSize">1m</property>
<!--
单位为k
-->
<property name="spillsFileBufferSize">1k</property>
<property name="useStreamOutput">0</property>
<!--
单位为m
-->
<property name="systemReserveMemorySize">384m</property>
<!--是否采用zookeeper协调切换 -->
<property name="useZKSwitch">true</property>
</system>
<!-- 全局SQL防火墙设置 -->
<!--
<firewall>
<whitehost>
<host host="127.0.0.1" user="mycat"/>
<host host="127.0.0.2" user="mycat"/>
</whitehost>
<blacklist check="false">
</blacklist>
</firewall>
-->
<!-- mycat登录用户密码和逻辑库名 -->
<user name="mycat">
<property name="password">123456</property>
<property name="schemas">TESTDB</property>
<!-- 表级 DML 权限设置 -->
<!--
<privileges check="false">
<schema name="TESTDB" dml="0110" >
<table name="tb01" dml="0000"></table>
<table name="tb02" dml="1111"></table>
</schema>
</privileges>
-->
</user>
<user name="user">
<property name="password">user</property>
<property name="schemas">TESTDB</property>
<property name="readOnly">true</property>
</user>
</mycat:server>
5.schema.xml编辑
vi /Users/zenghui/Desktop/Docker/mycat/mycat/conf/schema.xml
<?xml version="1.0"?>
<!DOCTYPE mycat:schema SYSTEM "schema.dtd">
<mycat:schema xmlns:mycat="http://io.mycat/">
<schema name="TESTDB" checkSQLschema="false" sqlMaxLimit="100" dataNode="dn1">
</schema>
<dataNode name="dn1" dataHost="host1" database="mysql" />
<dataHost name="host1" maxCon="1000" minCon="10" balance="1" writeType="0" dbType="mysql" dbDriver="native" switchType="1" slaveThreshold="100">
<heartbeat>select user()</heartbeat>
<!-- can have multi write hosts -->
<writeHost host="hostM1" url="mycat_mysql-master1_1:3306" user="root"
password="123456">
<!-- can have multi read hosts -->
<readHost host="hostS1" url="mycat_mysql-slave1_1:3306" user="root" password="123456" />
</writeHost>
<writeHost host="hostM2" url="mycat_mysql-master2_1:3306" user="root"
password="123456">
<!-- can have multi read hosts -->
<readHost host="hostS2" url="mycat_mysql-slave2_1:3306" user="root" password="123456" />
</writeHost>
</dataHost>
</mycat:schema>
6.双主机配置
vi /Users/zenghui/Desktop/Docker/mycat/master1/my.cnf
[mysqld]
#主服务器唯一ID
server-id=1
#启用二进制日志
log-bin=mysql-bin
# 设置不要复制的数据库(可设置多个)
binlog-ignore-db=mysql
binlog-ignore-db=information_schema
#设置需要复制的数据库
binlog-do-db=test_db
#设置logbin格式
binlog_format=STATEMENT
# 在作为从数据库的时候，有写入操作也要更新二进制日志文件
log-slave-updates
#表示自增长字段每次递增的量，指自增字段的起始值，其默认值是1，取值范围是1 .. 65535
auto-increment-increment=2
# 表示自增长字段从哪个数开始，指字段一次递增多少，他的取值范围是1 .. 65535
auto-increment-offset=1
vi /Users/zenghui/Desktop/Docker/mycat/master2/my.cnf
[mysqld]
#主服务器唯一ID
server-id=3
#启用二进制日志
log-bin=mysql-bin
# 设置不要复制的数据库(可设置多个)
binlog-ignore-db=mysql
binlog-ignore-db=information_schema
#设置需要复制的数据库
binlog-do-db=test_db
#设置logbin格式
binlog_format=STATEMENT
# 在作为从数据库的时候，有写入操作也要更新二进制日志文件
log-slave-updates
#表示自增长字段每次递增的量，指自增字段的起始值，其默认值是1，取值范围是1 .. 65535
auto-increment-increment=2
# 表示自增长字段从哪个数开始，指字段一次递增多少，他的取值范围是1 .. 65535
auto-increment-offset=2
7.双从机配置
vi /Users/zenghui/Desktop/Docker/mycat/slave1/my.cnf
[mysqld]
#从服务器唯一ID
server-id=2
#启用中继日志
relay-log=mysql-relay
vi /Users/zenghui/Desktop/Docker/mycat/slave2/my.cnf
[mysqld]
#从服务器唯一ID
server-id=4
#启用中继日志
relay-log=mysql-relay
8.配置主从复制
1.在master主机上创建主从复制的用户
create user 'slave'@'%' IDENTIFIED BY '123456';
GRANT REPLICATION SLAVE,REPLICATION CLIENT ON *.* TO 'slave'@'%';
flush privileges;
2.从机配置主机binlog
CHANGE MASTER TO MASTER_HOST='mycat_mysql-master1_1',MASTER_USER='slave',MASTER_PASSWORD='123456',
MASTER_LOG_FILE='mysql-bin.000003',MASTER_LOG_POS=567;
start slave;
show slave status;
CHANGE MASTER TO MASTER_HOST='mycat_mysql-master2_1',MASTER_USER='slave',MASTER_PASSWORD='123456',
MASTER_LOG_FILE='mysql-bin.000003',MASTER_LOG_POS=852;
start slave;
show slave status;
3.主机互相复制
master1执行
CHANGE MASTER TO MASTER_HOST='mycat_mysql-master2_1',MASTER_USER='slave',MASTER_PASSWORD='123456',
MASTER_LOG_FILE='mysql-bin.000003',MASTER_LOG_POS=1020;
start slave;
show slave status;
master2执行
CHANGE MASTER TO MASTER_HOST='mycat_mysql-master1_1',MASTER_USER='slave',MASTER_PASSWORD='123456',
MASTER_LOG_FILE='mysql-bin.000003',MASTER_LOG_POS=567;
start slave;
show slave status;
9.配置读写分离
yum -y install java
./mycat start
10.测试读写分离
create table mytbl (id int notnull,NAME varchar(50));
INSERT INTO mytbl VALUES(3,@@hostname);
此时四台机器上数据都不一致
只会出现三台机器的数据
master2的数据读不到，证明master2是只写机器
2.验证高可用
停止master2docker stop mycat_mysql-master2_1
在mycat端可以插入数据，但是读不到了
INSERT INTO mytbl VALUES(3,@@hostname);
启动master2后主节点切换
