1) Timing tools

time 命令测量程序执行时间

callgrind工具

可以测量程序执行指令的总数量。

Ir means I refs，表示执行的指令的总数量。

callgrind_annotate callgrind.out.pid 指令

pid指进程，就是valgrind执行之后最左侧的数字。可以分析程序执行指令的详细信息。

/* File: swap.c
 * ------------
 * Insertion sort with 3 different possible swap routines, which differ in
 * where they store temporary: fixed stack array, var stack array, or alloc/free from heap
 */
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
// This version uses a fixed size stack buffer for the temp storage.
void swap_fixedstack(void *a, void *b, size_t sz)
{
    char tmp[8];
    memcpy(tmp, a, sz);
    memcpy(a, b, sz);
    memcpy(b, tmp, sz);
}
// This version uses a variable-sized stack buffer for the temp storage.
void swap_varstack(void *a, void *b, size_t sz)
{
    char tmp[sz];
    memcpy(tmp, a, sz);
    memcpy(a, b, sz);
    memcpy(b, tmp, sz);
}
// The version uses heap (malloc/free) for the temp storage.
void swap_heap(void *a, void *b, size_t sz)
{
    void *tmp = malloc(sz);
    memcpy(tmp, a, sz);
    memcpy(a, b, sz);
    memcpy(b, tmp, sz);
    free(tmp);
}
long insertion_sort(long arr[], size_t n, void (*swap)(void *, void *, size_t))
{
    long nswaps = 0;
    for (long i = 1; i < n; i++)
        for (long j = i-1; j >= 0 && arr[j+1] < arr[j]; j--) {
            swap(&arr[j+1], &arr[j], sizeof(arr[j]));
            nswaps++;
        }
    return nswaps;
}
void *init_heap(int num)
{
    return malloc(num); // to resolve malloc/free, warmup heap
}
static struct {
    void (*fn)(void *, void *, size_t);
    char *name;
} trials[] =
     {{swap_fixedstack, "using fixed-len stack array"},
      {swap_varstack, "using variable-len stack array"},
      {swap_heap, "in heap"}};
static const int nfns = sizeof(trials)/sizeof(*trials);
int main(int argc, char *argv[])
{
    const int nelems = 1415;  // ~1 million swaps
    long unsorted[nelems], arr[nelems];
    free(init_heap(8));
    for (int j = 0; j < nelems; j++) unsorted[j] = nelems - j;
    printf("This program will insertion sort an array of %d elems.\n", nelems);
    printf("When swapping elements, temp could be stored on stack or heap. What are relative costs?\n");
    printf("Run under callgrind, then annotate to find out!\n\n");
    for(int i = 0; i < nfns; i++) {
        memcpy(arr, unsorted, sizeof(unsorted));    // init array in same configuration for each trial
        long nswaps = insertion_sort(arr, nelems, trials[i].fn);
        printf("Insertion sort (%zu total swaps), swap stores temp %s\n", nswaps, trials[i].name);
    }
    return 0;
}
