// Make glint reflections, ice, snow, and car shaders for example.
// Flakes.osl, by Mads Drøschler
// Modified: 2021-02-31
// License MIT Copyright Mads Drøschler
// https://github.com/gkmotu/OSL-Shaders
// Modified: 2021-03-01 by Saul Espinosa for Redshift 3D. Added Metadata + Mapper Menu for Coordinate Space
vector TileHash ( output vector x, int tileSize ) {
x = mod(x,tileSize);
return noise("hash",x);
}
vector ID(vector x, int seed,int Tiling,int tileSize)
{
vector n = floor(x);
vector f = x-floor(x);
vector m = vector(8);
vector o;
for( int k=-1; k<=1; k++ ){
for( int j=-1; j<=1; j++ ){
for( int i=-1; i<=1; i++ ){
vector g = vector( float(i), float(j),float(k) );
Tiling? o = TileHash(n+g,tileSize) : o = noise("hash",n+g,seed);
vector r = g - f + (0.5+0.5*sin(M_2PI*o));
float s = dot(r, r);
s<m[0] ? m = vector(s, o[0], o[1]):0;
}}}
return vector( sqrt(m[0]), m[1]+m[2], m[1]+m[0]);
}
float IDs ( output float x, int seed )
{
x = -1000 + x * 2000;
x = int(trunc(x));
float x_ratio = noise("cell", vector(abs(x), abs(seed), 11));
return mix(0, 1, x_ratio);
}
shader Flakes
[[
string help = "Use the Flakes shader to create small glints in surfaces",
string label = "Flakes"
]]
(
// Inputs
float scale = 0.2
[[
int connectable = 0,
float min = 0.0,
float max = 25.0,
string help = "<ul><br><li>Scale the IDs up and down. ( This is disabled when Seamless Tiling is enabled )<br></li>"
"<li>Use the Tile Size instead when Seamless Tiling is enabled.</li></ul>"
]],
float Density = 1.0
[[
int connectable = 0,
float min = 0.0,
float max = 1.0,
string help = "<ul><br><li>0.0 will print 0% IDs<br></li>"
"<li>0.5 will print 50% of the IDs<br></li>"
"<li>1.0 will cover the whole surface with ID's</li></ul>"
]],
float Randomize = 0.5
[[
int connectable = 0,
float min = 0.0,
float max = 1.0,
string help = "<ul><br><br>A value between 0-1 that will rotate the IDs<br>"
"<li>If value is 0, the IDs will point straight up from the surface ( no glints )<br></li>"
"<li>If value is 0.5, the IDs will be rotated randomly around 180 deg. ( mild dispersion )<br></li>"
"<li>If value is 1, the IDs will be rotated randomly around 360 deg.( Very scattered dispersion )</li></ul>"
]],
int seed = 42
[[
int connectable = 0,
int min = 0,
int max = 100,
string help = "<br><br>Reshuffle the layout of the IDs"
]],
int Tiling = 0
[[
string widget = "checkBox",
string label = "Seamless Tiling",
int connectable = 0,
string help = "<ul><br><br><li>Plug the Flake Shader directly into the Physical Materials diffuse slot</li>"
"<br><li>Make a square plane, 100x100/250x250/etc.</li>"
"<br><li>Assign the material to the plane.</li>"
"<br><li>Enable Seamless Tiling.</li>"
"<br><li>Adjust the size of the texure details with the Tile Size parameter.</li>"
"<br><li>Bake an Arnold Albedo texture to .exr and convert it to .tx with mipmapping enabled, for optimal performance.</li><br>"
"<br>You now have a Seamless Tiling OSL Flake bitmap.</ul>"
]],
int tileSize = 10
[[
int min = 10,
int max = 50,
int connectable = 0,
string help = "<br><br>Increase value to sample more IDs on the seamless tile"
]],
int CSpace = 0
[[
string label = "Coord Space",
string widget = "mapper",
string options = "object:0|world:1|UV:3",
string help = "<ul><br><li>Object</li><br>"
"<li>World</li><br>"
"<li>UV (Texture)</li></ul>"
]],
// Output
output normal Out = 0.0,
output float A = 0,
)
{
// Coord Space
string mode;
point pos,s = P;
vector t = vector(u,v,0);
CSpace == 0 ? mode = "object" : mode = "world";
CSpace == 2 ? pos = transform("object",t) : pos = transform(mode,s);
Tiling ? pos = transform("object",t):0;
// Scale
!Tiling ? pos = pos : pos = pos*tileSize;
float sc = scale;
!Tiling ? sc = sc : sc = 1.0;
// Point
point p = (pos)/sc;
// Base Normal
vector Base_Normal = vector(0.5,0.5,1.0);
// Fetch global ID
vector k = ID( p,seed,Tiling,tileSize );
// Turn
float x = 0.5 + 0.5 * cos( k[1]*M_2PI );
float y = 0.5 + 0.5 * sin( k[1]*M_2PI );
float z = 0.5 + 0.5 * tan( k[1]*M_2PI );
// Normalize
Out = normalize(vector(x,y,z)*2-1)*0.5+0.5;
// Fetch xyz IDs
Out[0] = IDs(Out[0],4);
Out[1] = IDs(Out[1],4);
Out[2] = IDs(Out[2],1);
// Fit z to 0.5 - 1.0
Out[2] = 0.5 + 0.5 *Out[2];
// Density
float h = -1000 + Out[0]*2000;
h = int(trunc(h));
float Rehash = noise("cell", vector(abs(h), abs(16), 11));
Rehash = mix(0, 1, Rehash);
Density > Rehash ? Out = Out : Out = Base_Normal;
// A
Out[0] > 0.5 or Out[0] < 0.5 ? A = 1 : A = 0;
// Randomize
Out = mix(Base_Normal,Out,Randomize);
//Out = Out*2-1;
}
