概述

  1. 本文主要讲Flink jobManager的实现。从源码角度分析其功能，内部核心组成及任务调度执行流程。主要从以下几个角度切入:
    • JobManager简介
    • 内部SchedulerNG介绍，任务调度执行流程。
    • 内部Scheduler、SlotPool介绍，资源分配流程。
  2. 一些更细节的东西，shuffleMaster，checkPoint，coodinator等暂不讨论。

JobManager简介

对于Flink我们都知道，有Dispatcher负责所有任务的分配，管理启动等。JM则负责单个任务的生命周期，包括JobGraph至ExecutionGraph构建，任务资源申请以及调度执行,checkPoint等。在实现上，JobMaster为其实现类，其内部由几个核心组件:SlotPool,Scheduler,SchedulerNG。如下类图关系：


  • SlotPool：其直接与ResourceManager连接，负责资源申请，保存。
  • Scheduler：根据不同策略，调度SlotPool申请资源。
  • SchedulerNG：实现类为DefaultScheduler，初始化ExecutionGraph，根据不同的调度策略，向Scheduler申请资源并提交任务。

JM构建时，会创建SchedulerNG，触发ExecutionGraph的构建。在JM启动后，SlotPool连接ResourceManager，SchedulerNG分配作业并向scheduler申请slot，scheduler根据不同策略向SlotPool申请资源，申请成功后ExecutionVertex进行Deploy。简略流程调用图如下：


SchedulerNG，任务调度流程

SchedulerNG负责更细粒度的task，包括ExucutionGraph构建，单个task级别调度，checkPoint触发，任务状态，恢复重启等管理。

JobMaster中很多对外的API直接委派给SchedulerNG。我们重点看下如何分配资源、执行任务。

  • 入口函数为：startScheduling(),在父类中，注册Metric，启动OperatorCoordinators，具体调度由子类实现。

OperatorCoordinator持有者OperatorCoordinatorHolder由job manager调用，提供了一个上下文去负责checkPoint协调和精准一次消费语义。这里暂不深入讨论。

  1. public final void startScheduling() {
  2.     mainThreadExecutor.assertRunningInMainThread();
  3.     registerJobMetrics();
  4.     startAllOperatorCoordinators();
  5.     startSchedulingInternal();
  6. }
  7. //schedule实现
  8. protected void startSchedulingInternal() {
  9.     log.info("Starting scheduling with scheduling strategy [{}]", schedulingStrategy.getClass().getName());
  10.     prepareExecutionGraphForNgScheduling(); //状态转换
  11.     schedulingStrategy.startScheduling(); //根据不同策略调度
  12. }
  • 调度策略
    • PipelinedRegionSchedulingStrategy：流水线任务调度
    • EagerSchedulingStrategy：所有任务同时调度 ,这是流式默认
    • LazyFromSourcesSchedulingStrategy：源数据到达之后再调度，对应批处理

  • 我们看下Eager调度
    因为所有任务同时调度，因此直接将verticesTopo转换成deploymentOptions，交由schedulerNG申请资源并deploy。

    1. private void allocateSlotsAndDeploy(final Set<ExecutionVertexID> verticesToDeploy) {
    2.   final List<ExecutionVertexDeploymentOption> executionVertexDeploymentOptions =
    3.       SchedulingStrategyUtils.createExecutionVertexDeploymentOptionsInTopologicalOrder(
    4.       schedulingTopology,
    5.       verticesToDeploy,
    6.       id -> deploymentOption);//转换
    7.   schedulerOperations.allocateSlotsAndDeploy(executionVertexDeploymentOptions);//schedulerOperations即为schedulerNG
    8. }

  • schedulerNG资源申请
    先根据exeuctionVertex构建request，再调用executionSlotAllocator申请资源。
    ExecutionJobVertex是并行的体现，内部持有每一个并行的ExecutionVertex和需要的资源等信息。

    1. private List<SlotExecutionVertexAssignment> allocateSlots(final List<ExecutionVertexDeploymentOption> executionVertexDeploymentOptions) {
    2.       return executionSlotAllocator.allocateSlotsFor(executionVertexDeploymentOptions
    3.           .stream()
    4.           .map(ExecutionVertexDeploymentOption::getExecutionVertexId)
    5.           .map(this::getExecutionVertex)
    6.           .map(ExecutionVertexSchedulingRequirementsMapper::from)
    7.           .collect(Collectors.toList()));
    8. }

  • ExecutionSlotAllocator申请资源，代码有点长略过一部分，大概意思是：先拿出预分配的，后遍历每一个请求，计算出首选位置然后组成Unit再去申请。

    1. public List<SlotExecutionVertexAssignment> allocateSlotsFor(
    2.           List<ExecutionVertexSchedulingRequirements> executionVertexSchedulingRequirements) {
    3.       //略
    5.       Set<AllocationID> allPreviousAllocationIds = computeAllPriorAllocationIds(executionVertexSchedulingRequirements);
    7.       for (ExecutionVertexSchedulingRequirements schedulingRequirements : executionVertexSchedulingRequirements) {
    8.           final ExecutionVertexID executionVertexId = schedulingRequirements.getExecutionVertexId();
    9.           final SlotRequestId slotRequestId = new SlotRequestId();
    10.           final SlotSharingGroupId slotSharingGroupId = schedulingRequirements.getSlotSharingGroupId();
    12.           LOG.debug("Allocate slot with id {} for execution {}", slotRequestId, executionVertexId);
    14.           CompletableFuture<LogicalSlot> slotFuture = calculatePreferredLocations(
    15.                   executionVertexId,
    16.                   schedulingRequirements.getPreferredLocations(),
    17.                   inputsLocationsRetriever).thenCompose(
    18.                           (Collection<TaskManagerLocation> preferredLocations) ->
    19.                               slotProviderStrategy.allocateSlot(
    20.                                   slotRequestId,
    21.                                   new ScheduledUnit(
    22.                                       executionVertexId,
    23.                                       slotSharingGroupId,
    24.                                       schedulingRequirements.getCoLocationConstraint()),
    25.                                   SlotProfile.priorAllocation(
    26.                                       schedulingRequirements.getTaskResourceProfile(),
    27.                                       schedulingRequirements.getPhysicalSlotResourceProfile(),
    28.                                       preferredLocations,
    29.                                       Collections.singletonList(schedulingRequirements.getPreviousAllocationId()),
    30.                                       allPreviousAllocationIds)));
    31.       //略
    32.   }

  • 我们看如何为每个ExcutionVertex计算首选位置(略过预分配的)
    这个是根据输入源的位置确定的，如果source尚未启动，返回的是空集。

    1. static CompletableFuture<Collection<TaskManagerLocation>> getPreferredLocationsBasedOnInputs(
    2.           ExecutionVertexID executionVertexId,
    3.           InputsLocationsRetriever inputsLocationsRetriever) {
    4.       CompletableFuture<Collection<TaskManagerLocation>> preferredLocations =
    5.               CompletableFuture.completedFuture(Collections.emptyList());
    7.       Collection<CompletableFuture<TaskManagerLocation>> locationsFutures = new ArrayList<>();
    9.   //获取输入源
    10.       Collection<Collection<ExecutionVertexID>> allProducers =
    11.               inputsLocationsRetriever.getConsumedResultPartitionsProducers(executionVertexId);
    12.       for (Collection<ExecutionVertexID> producers : allProducers) {
    14.           for (ExecutionVertexID producer : producers) {
    15.               Optional<CompletableFuture<TaskManagerLocation>> optionalLocationFuture =
    16.                       inputsLocationsRetriever.getTaskManagerLocation(producer);
    17.               optionalLocationFuture.ifPresent(locationsFutures::add);
    18.               // If the parallelism is large, wait for all futures coming back may cost a long time.
    19.               //输入源并行度超过8个的话，不进行计算。
    20.               if (locationsFutures.size() > MAX_DISTINCT_LOCATIONS_TO_CONSIDER) {
    21.                   locationsFutures.clear();
    22.                   break;
    23.               }
    24.           }
    26.           //输入源为空的话，返回空集
    27.           CompletableFuture<Collection<TaskManagerLocation>> uniqueLocationsFuture =
    28.                   FutureUtils.combineAll(locationsFutures).thenApply(HashSet::new);
    29.           preferredLocations = preferredLocations.thenCombine(
    30.                   uniqueLocationsFuture,
    31.                   (locationsOnOneEdge, locationsOnAnotherEdge) -> {
    32.                       if ((!locationsOnOneEdge.isEmpty() && locationsOnAnotherEdge.size() > locationsOnOneEdge.size())
    33.                               || locationsOnAnotherEdge.isEmpty()) {
    34.                           return locationsOnOneEdge;
    35.                       } else {
    36.                           return locationsOnAnotherEdge;
    37.                       }
    38.                   });
    39.           locationsFutures.clear();
    40.       }
    41.       return preferredLocations;
    42.   }

  • 计算出首选位置后，我们看具体执行分配动作。分配的话有不同策略实现，目前有如下两种策略：

    • BatchSlotProviderStrategy：这个只有在ScheduleMode设置为LAZY_FROM_SOURCES_WITH_BATCH_SLOT_REQUEST时才是。
    • NormalSlotProviderStrategy：默认流，批都是走这个分配策略。

NormalSlotProviderStrategy正常的分配：首先根据是否ShraingGroupId，选择不同的分配流程(group模式相对复杂，暂先不讨论)

  1. private void internalAllocateSlot(
  2.     CompletableFuture<LogicalSlot> allocationResultFuture,
  3.     SlotRequestId slotRequestId,
  4.     ScheduledUnit scheduledUnit,
  5.     SlotProfile slotProfile,
  6.     Time allocationTimeout) {
  7.     CompletableFuture<LogicalSlot> allocationFuture = scheduledUnit.getSlotSharingGroupId() == null ?
  8.         allocateSingleSlot(slotRequestId, slotProfile, allocationTimeout) :
  9.     allocateSharedSlot(slotRequestId, scheduledUnit, slotProfile, allocationTimeout);
  10. }
  • 资源申请完事了，deploy相对来说就简单了。根据申请来的slot，deployOption等组成DeploymentHandle。首先LogicalSlot assignSlot，然后构造TDD进行deploy。 ```java private void waitForAllSlotsAndDeploy(final List deploymentHandles) { FutureUtils.assertNoException(
    1.   assignAllResources(deploymentHandles).handle(deployAll(deploymentHandles)));
    } //assign 略一部分代码 public boolean tryAssignResource(final LogicalSlot logicalSlot) { // only allow to set the assigned resource in state SCHEDULED or CREATED // note: we also accept resource assignment when being in state CREATED for testing purposes if (state == SCHEDULED || state == CREATED) {
    1.   if (assignedResource == null) {
    2.       assignedResource = logicalSlot;
    3.       if (logicalSlot.tryAssignPayload(this)) {
    4.           // check for concurrent modification (e.g. cancelling call)
    5.           if ((state == SCHEDULED || state == CREATED) && !taskManagerLocationFuture.isDone())                     {
    6.               taskManagerLocationFuture.complete(logicalSlot.getTaskManagerLocation());
    7.               assignedAllocationID = logicalSlot.getAllocationId();
    8.               return true;
    9.           }
    10.       }
    11.   }
    } }

//deploy private void deployTaskSafe(final ExecutionVertexID executionVertexId) { try { final ExecutionVertex executionVertex = getExecutionVertex(executionVertexId); executionVertexOperations.deploy(executionVertex); } catch (Throwable e) { handleTaskDeploymentFailure(executionVertexId, e); } } //默认直接调用executionVertex::deploy class DefaultExecutionVertexOperations implements ExecutionVertexOperations { @Override public void deploy(final ExecutionVertex executionVertex) throws JobException { executionVertex.deploy(); } }

  2. <a name="Scheduler"></a>
  3. ### Scheduler
  5. Scheduler更主要的是slotProvider的实现。负责资源的申请，包括shraing模式的分配，以及根据不同策略申请slot。我们看下slotProvider接口：
  7. ```java
  8. CompletableFuture<LogicalSlot> allocateSlot();
  9. default CompletableFuture<LogicalSlot> allocateBatchSlot();
  10. default CompletableFuture<LogicalSlot> allocateSlot();
  11. void cancelSlotRequest();
  • 上面说到，在不同slotProvdier策略下，最终都会由Scheduler实现最终的资源分配。如下是对应上面，分配单个槽的思路：

当未开启sharingGroup时，会先尝试从本地已有分配，本地没有则时申请slot。

  1. private CompletableFuture<LogicalSlot> allocateSingleSlot(
  2.             SlotRequestId slotRequestId,
  3.             SlotProfile slotProfile,
  4.             @Nullable Time allocationTimeout) {
  6.     Optional<SlotAndLocality> slotAndLocality = tryAllocateFromAvailable(slotRequestId, slotProfile);
  8.     if (slotAndLocality.isPresent()) {
  9.         // already successful from available
  10.         try {
  11.             return CompletableFuture.completedFuture(
  12.                 completeAllocationByAssigningPayload(slotRequestId, slotAndLocality.get()));
  13.         } catch (FlinkException e) {
  14.             return FutureUtils.completedExceptionally(e);
  15.         }
  16.     } else {
  17.         // we allocate by requesting a new slot
  18.         return requestNewAllocatedSlot(slotRequestId, slotProfile, allocationTimeout)
  19.             .thenApply((PhysicalSlot allocatedSlot) -> {
  20.                 try {
  21.                     return completeAllocationByAssigningPayload(slotRequestId, new SlotAndLocality(allocatedSlot, Locality.UNKNOWN));
  22.                 } catch (FlinkException e) {
  23.                     throw new CompletionException(e);
  24.                 }
  25.             });
  26.     }
  27. }

  • requestNewSlot根据是否有超时时间，判断走流或批的申请

    1. private CompletableFuture<PhysicalSlot> requestNewAllocatedSlot(
    2.           SlotRequestId slotRequestId,
    3.           SlotProfile slotProfile,
    4.           @Nullable Time allocationTimeout) {
    5.   if (allocationTimeout == null) {
    6.       return slotPool.requestNewAllocatedBatchSlot(slotRequestId,         slotProfile.getPhysicalSlotResourceProfile());
    7.   } else {
    8.       return slotPool.requestNewAllocatedSlot(slotRequestId, slotProfile.getPhysicalSlotResourceProfile(), allocationTimeout);
    9.   }
    10. }

  • slotPool中实现最终通过rpc调用向resourceManager申请，这涉及到taskManager等，例如yarn per-job模式时，这里申请slot就会启动taskManager，也就是yarn上的container。

    1. CompletableFuture<Acknowledge> rmResponse = resourceManagerGateway.requestSlot(
    2.   jobMasterId,
    3.   new SlotRequest(jobId, allocationId, pendingRequest.getResourceProfile(), jobManagerAddress),
    4.   rpcTimeout);
