Metrics SDK

TODO: TOC

Purpose

This document has two parts. In the first part, the requirements of the default OpenTelemetry Metric SDK are listed. These are rules for language implementors to follow in any approach to implementing the OpenTelemetry API.

In the second part, the architectural details of a model SDK implementation are described, using the OpenTelemetry-Go Metric SDK as an example. This is meant to show how the requirements can be implemented, as guidance for implementors, not to mandate an exact reproduction of the model architecture across languages. OpenTelemetry SDKs are of course free to use any idiomatic approach.

Expectations

This document assumes you are familiar with the OpenTelemetry Metrics API specification.

The SDK implementors are expected to follow the best practices for the language and runtime environment when implementing the OpenTelemetry API. Implementors SHOULD follow the general prescriptions on safety and performance given in OpenTelemetry library guidelines.

SDK Terminology

The Metrics SDK provides an implementation of the Metrics API, which has terms that it uses to refer to the SDK:

• Meter: An interface that supplies the OpenTelemetry Metric API, bound together with Resources and the Instrumentation Library
• MeterProvider: An interface for obtaining Meter instances given the Instrumentation Library.

These terms are useful to describe the boundary between the API and the SDK, but they are API-level constructs. We can use API-level terms to describe the boundary between the SDK and the API, but from the API’s perspective the SDK is opaque and without structure.

This document specifies the internal structure of the default OpenTelemetry SDK in terms of its major components, with terminology chosen to explain each component’s role in exporting metric data from the input (API-level events) to the output (a metric exposition format). We use the term Export Pipeline as a functional description of the SDK at this level.

There are three major components of the export pipeline that data flows through, in order:

1. Accumulator: Receives metric events from the API through Instruments, computes one Accumulation per active Instrument and Label Set pair
2. Processor: Receives Accumulations from the Accumulator, transforms into ExportRecordSet
3. Exporter: Receives ExportRecordSet, transforms into some protocol and sends it somewhere.

The Controller component coordinates the Accumulator, Processor, and Exporter in an export pipeline.

These terms are defined in the Metrics API specification:

• Metric Instrument: the API object used by a developer for instrumentation
• Synchronous Instrument: a metric instrument called by the user with application context
• Asynchronous Instrument: a metric instrument invoked through a callback from the SDK
• Metric Descriptor: describes a metric instrument
• Metric Event: a single recorded or observed (Instrument, Label Set, Measurement)
• Collection Interval: the period between calls to Accumulator.Collect()
• Label: a key-value describing a property of the metric event
• Label Set: a set of key-values with unique keys
• Measurement: an integer or floating point number from a synchronous instrument
• Observation: an integer or floating point number from an asynchronous instrument.

Defined in the Resource SDK specification:

• Resource: a set of key-values with unique keys describing the process
• Instrumentation Library: the name and version associated with a package of instrumentation.

These are the significant data types used in the model architecture:

• Aggregator: aggregates one or more measurements in a useful way
• Aggregator Snapshot: copy of an synchronous instrument aggregator taken during collection
• AggregatorSelector: chooses which Aggregator to assign to a metric instrument
• Accumulation: consists of Instrument, Label Set, Resource, and Aggregator snapshot, output by Accumulator
• Aggregation: the result of aggregating one or more events by a specific aggregator, output by Processor
• AggregationKind: describes the kind of read API the Aggregation supports (e.g., Sum)
• ExportKind: one of Delta, Cumulative, or Pass-Through
• ExportKindSelector: chooses which ExportKind to use for a metric instrument.
• ExportRecord: consists of Instrument, Label Set, Resource, Timestamp(s), and Aggregation
• ExportRecordSet: a set of export records.

The term SDK instrument refers to the underlying implementation of an instrument.

Dataflow Diagram

From an external perspective, the Metrics SDK implements the Meter and MeterProvider interfaces described in the Metrics API. From an internal perspective, the Metrics SDK encapsulates an export pipeline for metric data consisting of four major components.

The Accumulator component is where metric events are concurrently passed to an Aggregator, and it is this component that is most responsible for SDK performance. The Accumulator is responsible for organizing bound and unbound instruments, updating and synchronized copying of Aggregator state, invoking Observer instruments, and the collection cycle.

The Processor component is intended as the most customizable component in the export pipeline. The Processor is responsible for selecting Aggregators to use for specific instruments, via an independent AggregationSelector interface, for reducing dimensionality, and for conversion between DELTA and CUMULATIVE data point representation. The Processor interface supports arbitrary protocol-independent data transformation, and Processors can be chained together to form more complex export pipelines.

The Exporter component converts processed data into a specific protocol and exports it somewhere. Following the library guidelines, exporters are expected to contain minimal functionality and customization is preferably expressed through Processors.

The Controller component coordinates the sequence of actions to collect, process, and export metric data over a collection interval, ensuring that access to the export pipeline is properly synchronized.

Requirements

Requirements are listed below for the major components of the OpenTelemetry SDK using the terminology outlined above.

The data flow diagram above is meant as an abstraction, for understanding how the standard component names used in this document map into a data path. The diagram is not meant to prescribe an overall architecture for the SDK, just to name the stages of an export pipeline and place them in context.

SDKs are required to use the standard names for these components, as this helps build consistency across OpenTelemetry. Every SDK SHOULD include these components and the interfaces detailed below, although the actual organization of each SDK may differ depending on the available libraries and performance characteristics of the source language. For example, an SDK could be implemented using one Accumulator per instrument or it could be implemented using one Accumulator per collection period (assuming support for multiple collection periods): these are considered implementation details.

SDK

The SDK encapsulates an OpenTelemetry Metric export pipeline, implementing the Meter interface, and managing the SDK instrument, the Resource, and Instrumentation Library metadata.

MeterProvider

Shutdown

This method provides a way for provider to do any cleanup required.

Shutdown MUST be called only once for each MeterProvider instance. After the call to Shutdown, subsequent attempts to get a Meter are not allowed. SDKs SHOULD return a valid no-op Meter for these calls, if possible.

Shutdown SHOULD provide a way to let the caller know whether it succeeded, failed or timed out.

Shutdown SHOULD complete or abort within some timeout. Shutdown can be implemented as a blocking API or an asynchronous API which notifies the caller via a callback or an event. Language library authors can decide if they want to make the shutdown timeout configurable.

SDK: Instrument Registration

The OpenTelemetry SDK is responsible for ensuring that an individual Meter implementation cannot report multiple instruments with the same name and different definitions. To accomplish this, SDKs MUST reject duplicate registration of an instrument when another instrument has already been registered with same metric name to the same named Meter. The requirement applies even for attempts to register an identical instrument definition. We assume that a single instrumentation library can arrange to use a single instrument definition rather than rely on the SDK to support duplicate registration.

Separate Meters, characterized by different instrumentation library names, are permitted to register instruments by the same name as used in different instrumentation libraries, in which case the SDK MUST consider these as separate instruments.

The SDK is responsible for implementing any syntactic requirements for metric names included in the API specification. TODO: link to this after OTEP 108 is written into the API specification.

SDK: RecordBatch() function

TODO: Add functional requirements for RecordBatch().

SDK: Collect() function

The SDK is responsible for implementing a Collect() function that calls through to one or more Accumulators. This specification deliberately avoids requiring a specific relationship between the SDK and Accumulator; it is considered an implementation detail whether a the SDK maintains one Accumulator, one Accumulator per instrument, or some configuration in between.

The SDK Collect() function MUST call through to the Processor with Accumulations from the active synchronous instruments as well as all the registered asynchronous instruments.

The SDK MUST permit synchronous metric instruments to be used during evaluation of asynchronous instrument callbacks. The use of synchronous instruments from asynchronous instrument callbacks is considered a side-effect, in this case. SDKs SHOULD process synchronous instruments after asynchronous instruments, so that side-effect synchronous measurements are processed as part of the same collection interval that contains the corresponding asynchronous observations.

Accumulator

The diagram below shows the relationship between the API and the Accumulator, with detail shown for synchronous instruments.

For a synchronous instrument, the Accumulator will:

1. Map each active Label Set to a record, consisting of two instances of the same type Aggregator
2. Enter new records into the mapping, calling the AggregationSelector if needed
3. Update the current Aggregator instance, responding to concurrent API events
4. Call Aggregator.SynchronizedMove on the current Aggregator instance to: (a) copy its value into the snapshot Aggregator instance and (b) reset the current Aggregator to the zero state
5. Call Processor.Process for every resulting Accumulation (i.e., Instrument, Label Set, Resource, and Aggregator snapshot)

The Accumulator MUST provide the option to associate a Resource with the Accumulations that it produces.

Synchronous metric instruments are expected to be used concurrently. Unless concurrency is not a feature of the source language, the SDK Accumulator component SHOULD be designed with concurrent performance in mind.

The Accumulator MAY use exclusive locking to maintain a map of synchronous instrument updates. The Accumulator SHOULD NOT hold an exclusive lock while calling an Aggregator (see below), since some Aggregators may have higher concurrency expectations.

Accumulator: Collect() function

The Accumulator MUST implement a Collect method that builds and processes current Accumulation values for active instruments, meaning those that were updated since the prior collection. The Collect method MUST call the Processor to process Accumulations corresponding to all metric events that happened before the call.

Accumulations MUST be computed during Collect using a synchronized move operation on the Aggregator. This operation, using some kind of synchronization, copies the current Aggregator and resets it to the zero state, so that each Aggregator immediately begins accumulating events for the next collection period while the current one is processed. An Accumulation is defined as the synchronously-copied Aggregator combined with the Label Set, Resource, and metric Descriptor.

TODO: Are there more Accumulator functional requirements?

Processor

TODO Processor functional requirements

Controller

TODO Controller functional requirements

Aggregator

TODO Aggregator functional requirements

The Sum Aggregator SHOULD use atomic operations, if possible and where there is concurrency.

Model Implementation

The model implementation is based on the OpenTelemetry-Go SDK. This section is meant as guidance for implementors, SDK implementors are of course recommended to use an idiomatic approach in their source language.

Accumulator: Meter Implementation

To construct a new Accumulator, provide the Processor and options.

// NewAccumulator constructs a new Accumulator for the given
// Processor and options.
func NewAccumulator(processor export.Processor, opts ...Option) *Accumulator
// WithResource sets the Resource configuration option of a Config.
func WithResource(res *resource.Resource) Option

The Accumulator is called by the Controller (see below) to coordinate collection using a Collect() method.

// Collect traverses the list of active instruments and exports
// data.  Collect() may not be called concurrently.
//
// During the collection pass, the Processor will receive
// one Process(Accumulation) call per current aggregation.
//
// Returns the number of accumulations that were exported.
func (m *Accumulator) Collect(ctx context.Context) int

Implement the SDK-level API matching the user-level Metric API

This interface sits at the boundary of the SDK and the API, with three core methods:

// MeterImpl is the interface an SDK must implement to supply a Meter
// implementation.
type MeterImpl interface {
        // RecordBatch atomically records a batch of measurements.
        RecordBatch(context.Context, []label.KeyValue, ...Measurement)
        // NewSyncInstrument returns a newly constructed
        // synchronous instrument implementation or an error, should
        // one occur.
        NewSyncInstrument(descriptor Descriptor) (SyncImpl, error)
        // NewAsyncInstrument returns a newly constructed
        // asynchronous instrument implementation or an error, should
        // one occur.
        NewAsyncInstrument(
                descriptor Descriptor,
                runner AsyncRunner,
        ) (AsyncImpl, error)
}

These methods cover all the necessary entry points for implementing the OpenTelemetry Metric API.

RecordBatch is a user-level API implemented directly by the Accumulator.

The two instrument constructors build synchronous and asynchronous SDK instruments.

The user is generally interested in the Metric API Meter interface, obtained through a Metric API MeterProvider interface. The Meter interface can be constructed by wrapping the SDK Meter implementation:

// WrapMeterImpl constructs a named `Meter` implementation from a
// `MeterImpl` implementation.  The `instrumentationName` is the
// name of the instrumentation library.
func WrapMeterImpl(impl MeterImpl, instrumentationName string, opts ...MeterOption) Meter

Optional to this method:

• the instrumentation library version of the named Meter in use.

To help with instrumentat registration:

// NewUniqueInstrumentMeterImpl returns a wrapped metric.MeterImpl with
// the addition of uniqueness checking.
func NewUniqueInstrumentMeterImpl(impl metric.MeterImpl) metric.MeterImpl {

Provide access to the instrument descriptor

The API Descriptor method defines the instrument in terms of API-level constructs including name, instrument kind, description, and units of measure. The SDK instrument MUST provide access to the Descriptor that was passed to its constructor.

// InstrumentImpl is a common interface for synchronous and
// asynchronous instruments.
type InstrumentImpl interface {
        // Descriptor returns a copy of the instrument's Descriptor.
        Descriptor() Descriptor
}

Synchronous SDK instrument

The synchronous SDK instrument supports both direct and bound calling conventions.

// SyncImpl is the implementation-level interface to a generic
// synchronous instrument (e.g., ValueRecorder and Counter instruments).
type SyncImpl interface {
        // InstrumentImpl provides Descriptor().
        InstrumentImpl
        // Bind creates an implementation-level bound instrument,
        // binding a label set with this instrument implementation.
        Bind(labels []label.KeyValue) BoundSyncImpl
        // RecordOne captures a single synchronous metric event.
        RecordOne(ctx context.Context, number Number, labels []label.KeyValue)
}
// BoundSyncImpl is the implementation-level interface to a
// generic bound synchronous instrument
type BoundSyncImpl interface {
        // RecordOne captures a single synchronous metric event.
        RecordOne(ctx context.Context, number Number)
        // Unbind frees the resources associated with this bound instrument.
        Unbind()
}

Asynchronous SDK instrument

The asynchronous SDK instrument supports both single-observer and batch-observer calling conventions. The interface used for running Observer callbacks is passed at the constructor, so there are no other API-level access methods for asynchronous instruments.

// AsyncImpl is an implementation-level interface to an
// asynchronous instrument (e.g., Observer instruments).
type AsyncImpl interface {
        // InstrumentImpl provides Descriptor().
        InstrumentImpl
}

The asynchronous “runner” interface (AsyncRunner) passed in the asynchronous SDK instrument constructor supports both single and batch calling conventions. These are considered language-specific details.

Export pipeline detail

TODO: define AggregatorSelector, Aggregator, Accumulation, ExportKind, ExportKindSelector, Aggregation, AggregationKind ExportRecord, ExportRecordSet

Processor Detail

TODO: define the Processor interface

Basic Processor

TODO: define how ExportKind conversion works (delta->cumulative required, cumulative->delta optional), Memory option (to not forget prior collection state).

Reducing Processor

TODO: Label filter, LabelFilterSelector

Controller Detail

TODO: Push, Pull

Aggregator Implementations

TODO: Sum, LastValue, Histogram, MinMaxSumCount, Exact, and Sketch.

Pending issues

ValueRecorder instrument default aggregation

TODO: The default SDK behavior for ValueRecorder instruments is still in question. Options are: LastValue, Histogram, MinMaxSumCount, and Sketch.

Spec issue 636 OTEP 117 OTEP 118

Standard sketch histogram aggregation

TODO: T.B.D.: DDSketch considered a good choice for ValueRecorder instrument default aggregation.
